16 mm and 19 mm panel-mount push buttons

What panel hole does a 16 mm or 19 mm push button need? · Hardware · basis: common vendor dimensions (metal 'anti-vandal' and arcade styles)

Also called: 16mm button, 19mm button, arcade button, momentary button cutout, panel mount switch

Exact dimensions. Every file is drawn at true size with no tolerance added. The holes and pins that meet another part are listed below under Mating features, with the fit each joint needs; open those by your process's clearance before making the part. Mating features

sizes
6 in table

Notes

  • Metal panel-mount buttons: 12 mm → Ø12.2 hole, 16 mm → Ø16.2, 19 mm → Ø19.2, 22 mm → Ø22.3; max panel thickness usually 3–10 mm depending on the nut.
  • Arcade-style snap-in buttons: 24 mm → Ø24 hole, 30 mm → Ø30; panel 2–5 mm.
  • Depth behind panel: 25–35 mm for the body plus wire.
  • No downloadable true-size file yet: the published figures do not fix the whole shape, and Xem never guesses a number. A measured scan is planned; request it to move it up.

16 mm and 19 mm panel-mount push buttons size chart

buttonpanel hole (mm)max panel (mm)depth behind (mm)
12 mm metal12.2825
16 mm metal16.21030
19 mm metal19.21032
22 mm metal22.31035
24 mm arcade24.0532
30 mm arcade30.0532

Mating features

Drawn at the exact size. Open press, slide, run and socket features by your process's clearance (tolerances by process); leave designed gaps and clamp fits as drawn.

featureexactmates withfitfiles
panel-mount body12 / 16 / 19 / 22 mm metal; 24 / 30 mm arcade snap-inpanel hole Ø12.2 / 16.2 / 19.2 / 22.3 (metal), Ø24.0 / Ø30.0 (arcade); max panel 8 / 10 / 10 / 10 and 5 / 5; depth behind panel 25 / 30 / 32 / 35 and 32 / 32designedall

Where the files are

Other publishers' files are linked, not hosted. "verify" = check the license at the link before commercial use.

McMaster-CarrPush-button switches (free STEP/IGES/STL per part, for your own design use; no redistribution)STEP, IGES, STL, PDFMcMaster-Carr site terms: personal design use, no redistribution verify

Xem scan

File coming

No downloadable true-size file yet: the published figures do not fix the whole shape, and Xem never guesses a number. A measured scan is planned; request it and it moves up.

Votes decide what gets scanned first.

+1 for a scan of 16 mm and 19 mm panel-mount push buttons

Your vote moves it up the list. Email is optional: only if you want one message when the file is ready.

Let your AI pull this. Add https://xemstudio.com/mcp to Claude, ChatGPT, Cursor or any MCP client (free, no account, one minute) and it can look up exact sizes, mating fits and free STEP/STL from every chat.
Set it up →

Plain text: sheet.txt · JSON: /api/geometry?object=16mm-arcade-button

hole
Schematic, not to scale.

Fits with

Questions

What hole size for a 16 mm push button?

16.2 mm. 12 mm buttons need 12.2, 19 mm need 19.2, 22 mm need 22.3; panel up to 3–10 mm thick depending on the nut.

What hole for a 24 mm or 30 mm arcade button?

Exactly 24 mm and 30 mm; snap-in style for 2–5 mm panels. Leave 30–35 mm behind the panel for the body and microswitch.
