18650 lithium cell

What are the exact dimensions of an 18650 cell for a holder? · Standard part · basis: industry standard (IEC 60086 naming); nominal values

Also called: 18650, 18650 battery, 18650 battery dimensions, batería 18650 medidas, bateria 18650 dimensões

Exact dimensions. Every file is drawn at true size with no tolerance added. The holes and pins that meet another part are listed below under Mating features, with the fit each joint needs; open those by your process's clearance before making the part. Mating features

length
65 mm
width
18 mm
height
18 mm

Notes

  • Nominal Ø18 × 65 mm; real cells run Ø18.2–18.6 mm and 65.0–65.3 mm, and protected cells up to ~69 mm long. Design holders for Ø18.6 and 65.5 unless you know the cell.
  • Button-top adds about 0.5–1 mm; flat-top is the common unprotected form.

Mating features

Drawn at the exact size. Open press, slide, run and socket features by your process's clearance (tolerances by process); leave designed gaps and clamp fits as drawn.

featureexactmates withfitfiles
cell bodynominal Ø18 × 65 (real Ø18.2–18.6 × 65.0–65.3, protected to about 69)battery holder cavity and spring/flat contacts; button top +0.5–1slideall

Where the files are

Other publishers' files are linked, not hosted. "verify" = check the license at the link before commercial use.

WikipediaList of battery sizeswebCC BY-SA 4.0 (text)

Free files

★ Free files 1 parts. Generated by Xem Studio from the standard; threads are plain cylinders at major diameter. CC BY 4.0. index.json

Use this part in your AI. Your AI gets the exact sizes and files straight from Xem and can design a mount, case or adapter around it. Direct downloads here are limited to one file every 10 minutes; through your AI they are unlimited.

Connect Xem to your AI (free, no account, about a minute)
https://xemstudio.com/mcp
  1. Claude: Add to Claude
  2. ChatGPT (Plus or higher): open Connectors → Advanced → turn on Developer mode → Create → paste the address, no authentication → Create.
  3. Cursor: install with one click. VS Code: install with one click.
Other apps and full steps
cell-1865018650 typical real size Ø18.3 × 65.2STEP · STL
Let your AI pull this. Add https://xemstudio.com/mcp to Claude, ChatGPT, Cursor or any MCP client (free, no account, one minute) and it can look up exact sizes, mating fits and free STEP/STL from every chat.
Set it up →

Plain text: sheet.txt · JSON: /api/geometry?object=18650-cell

18650 lithium cell, isometric render of a generated part
Render of cell-18650 from the free STEP; not to scale.

Fits with

Questions

What are the real dimensions of an 18650 cell?

Nominal Ø18 × 65 mm; real cells Ø18.2–18.6 and 65.0–65.3 mm, protected cells to about 69 mm. Design holders for Ø18.6 × 65.5.

Button top vs flat top 18650 length?

Button-top adds about 0.5–1 mm; flat-top is the common unprotected form used in packs.
