Ari tsugi (Japanese dovetail splice)
What is an ari tsugi joint? · Hardware · basis: Xem Studio design — geometry computed in the generator from traditional proportions
Also called: ari tsugi, 蟻継ぎ, japanese dovetail splice, dovetail splice joint, japanese joinery dovetail, empalme cola de milano japonés, japanische Schwalbenschwanzverbindung
Exact dimensions. True size, with no tolerance added.
- length
- 130.0 mm
- width
- 20.0 mm
- height
- 20.0 mm
Notes
- Woodworking joint drawn for 3D printing: the parts lock together by shape, so a print can be joined without glue or screws. Drawn at true size with the parts line to line (zero gap) in their assembled position — add your printer's fit allowance to the mating faces (your AI or slicer can do this).
- The simplest Japanese splice: a dovetail on one member drops into a socket in the other.
Ari tsugi size chart
| dimension | value |
|---|---|
| stock | 20 × 20 mm square |
| parts | male, female |
| dovetail | 8 mm neck → 13 mm head, 15 mm long, full height |
| assembles | the male drops in from above |
| holds | pulling apart lengthwise |
