ARRMA Kraton 8S BLX (1/5 speed monster truck, ARA110002)

What are the dimensions of the ARRMA Kraton 8S BLX? · Modern device · basis: Manufacturer specifications (ARRMA (Horizon Hobby))

Also called: arrma kraton 8s dimensions, kraton 8s size, kraton 8s wheelbase, kraton 8s battery size, kraton 8s 24mm hex, kraton 8s weight, 1/5 kraton length, medidas kraton 8s, arrma kraton 8s maße

Exact dimensions. True size, with no tolerance added.

length
760 mm
height
266 mm

Notes

  • The Kraton 8S is ARRMA's 1/5 speed monster truck. Width is not published, so the file is a 760 × 266 mm length × height envelope with wheel centres on a 491 mm wheelbase and 602 mm track.
  • Tire diameter is not published.
  • True size, no printing tolerance added. Only published numbers are used; anything not published is said so.

ARRMA Kraton 8S BLX size chart

dimensionvalue
Length29.92 in (760 mm)
Widthnot published
Height10.47 in (266 mm)
Wheelbase19.33 in (491 mm)
Front / rear track23.70 in (602 mm)
Weight24.2 lb (11 kg)
Wheel hex24 mm
Wheel width3.54 in (90 mm)
Max battery size7.09 × 2.16 × 2.09 in (180 × 55 × 53 mm)
MotorSpektrum Firma 4685 1250 Kv
ESCSpektrum Firma 160A Smart
ServoSpektrum S905

Where the files are

Other publishers' files are linked, not hosted. "verify" = check the license at the link before commercial use.

ARRMA (Horizon Hobby)ARRMA 1/5 Kraton 8S 4X4 RTRwebPublisher's page; dimensions are facts

Free files

★ Free files 1 parts. Generated by Xem Studio from the standard; threads are plain cylinders at major diameter. CC BY 4.0. index.json

Use this part in your AI. Your AI gets the exact sizes and files straight from Xem and can design a mount, case or adapter around it. Direct downloads here are limited to one file every 10 minutes; through your AI they are unlimited.

Connect Xem to your AI (free, no account, about a minute)
https://xemstudio.com/mcp
  1. Claude: Add to Claude
  2. ChatGPT (Plus or higher): open Connectors → Advanced → turn on Developer mode → Create → paste the address, no authentication → Create.
  3. Cursor: install with one click. VS Code: install with one click.
Other apps and full steps
arrma-kraton-8s-blx-wheel-centre-layoutWheel centres on a 491 × 602 mm rectangle (wheelbase × track), Ø10 × 1 mm markers — tire size not publishedSTEP · STL
Let your AI pull this. Add https://xemstudio.com/mcp to Claude, ChatGPT, Cursor or any MCP client (free, no account, one minute) and it can look up exact sizes, mating fits and free STEP/STL from every chat.
Set it up →

Plain text: sheet.txt · JSON: /api/geometry?object=arrma-kraton-8s-blx

ARRMA Kraton 8S BLX (1/5 speed monster truck, ARA110002), isometric render of a generated part
