DJI Avata 2 parts list

What parts does the DJI Avata 2 use, and what sizes are they? · Modern device · basis: Maker's manual / official spare-parts listing: part numbers and sizes as printed

Also called: DJI Avata 2 part numbers, DJI Avata 2 replacement parts, DJI Avata 2 spare parts, DJI Avata 2 parts diagram, DJI Avata 2 exploded view, DJI Avata 2 bearings, DJI Avata 2 screw sizes, repuestos DJI Avata 2, DJI Avata 2 Ersatzteile

Exact dimensions. True size, with no tolerance added.

length
185 mm
width
212 mm
height
64 mm

Notes

  • Every part number the maker publishes for the DJI Avata 2 — 3 parts, 3 with sizes printed in the source (bearings, screws, pins, props, servos, motors, batteries…). Sizes are copied exactly as printed; "not published" means the source gives none.
  • Files are the standard hardware in this list (bearings, screws, gears, props) at true size. Molded parts' shapes are not published, so they are not modelled; standard hardware links to its own pages.
  • Use it to rebuild or re-print the vehicle: order the numbered parts, print the rest to the published sizes.

DJI Avata 2 parts list size chart

part numberpartgroupsizes (as printed)qtyalso fits
3032SDJI Avata 2 propeller (pair)propsØ75.66 mm; approx. 1.74 g; pitch not publishedPropellers (pair) × 2 per pack—
not publishedDJI Avata 2 Intelligent Flight Batterybattery2150 mAh; 14.76 V, 17 V max charge; Li-ion; 31.7 Wh @0.5C; approx. 145 g; dimensions not published1—
not publishedPropeller screw (supplied with Avata 2 propellers)hardwareM2 × 8.7 mm8 per pack—

Where the files are

Other publishers' files are linked, not hosted. "verify" = check the license at the link before commercial use.

DJI StoreDJI Avata 2 PropellerswebPublisher's page; dimensions are facts
DJI StoreDJI Avata 2 Intelligent Flight BatterywebPublisher's page; dimensions are facts

Free files

★ Free files 1 parts. Generated by Xem Studio from the standard; threads are plain cylinders at major diameter. CC BY 4.0. index.json

Use this part in your AI. Your AI gets the exact sizes and files straight from Xem and can design a mount, case or adapter around it. Direct downloads here are limited to one file every 10 minutes; through your AI they are unlimited.

Connect Xem to your AI (free, no account, about a minute)
https://xemstudio.com/mcp
  1. Claude: Add to Claude
  2. ChatGPT (Plus or higher): open Connectors → Advanced → turn on Developer mode → Create → paste the address, no authentication → Create.
  3. Cursor: install with one click. VS Code: install with one click.
Other apps and full steps
dji-3032s-dji-avata-2-propeller-pair-swept-discSwept disc Ø75.66 mm, 1 mm reference — blades and hub not publishedSTEP · STL
Let your AI pull this. Add https://xemstudio.com/mcp to Claude, ChatGPT, Cursor or any MCP client (free, no account, one minute) and it can look up exact sizes, mating fits and free STEP/STL from every chat.
Set it up →

Plain text: sheet.txt · JSON: /api/geometry?object=dji-avata-2-parts-list

DJI Avata 2 parts list, isometric render of a generated part
Render of dji-3032s-dji-avata-2-propeller-pair-swept-disc from the free STEP; not to scale.
