Easy Composites 6 × 4 mm pultruded carbon tube

What are the dimensions of the Easy Composites 6 × 4 mm pultruded carbon tube? · Modern device · basis: Manufacturer specifications (Easy Composites)

Also called: 6mm carbon tube, 6x4 carbon tube, 6mm pultruded carbon tube, carbon wing spar 6mm, 6mm od 4mm id, tubo carbono 6mm, carbonrohr 6mm, 6x4x1000 carbon

Exact dimensions. True size, with no tolerance added.

length
6 mm
width
6 mm
height
1000 mm

Notes

  • From Easy Composites' product page; modelled at the 1000 mm length.
  • True size, no printing tolerance added. Only published numbers are used; anything not published is said so.

Easy Composites 6 × 4 mm pultruded carbon tube size chart

dimensionvalue
OD6 mm ±0.1
ID4 mm ±0.1
Wall1 mm
Lengths1000 mm, 2000 mm
Gross weight0.0235 kg
Fibre100% unidirectional carbon, epoxy

Where the files are

Other publishers' files are linked, not hosted. "verify" = check the license at the link before commercial use.

Easy Composites6mm (4mm) Pultruded Carbon Fibre TubewebPublisher's page; dimensions are facts

Free files

★ Free files 1 parts. Generated by Xem Studio from the standard; threads are plain cylinders at major diameter. CC BY 4.0. index.json

Use this part in your AI. Your AI gets the exact sizes and files straight from Xem and can design a mount, case or adapter around it. Direct downloads here are limited to one file every 10 minutes; through your AI they are unlimited.

Connect Xem to your AI (free, no account, about a minute)
https://xemstudio.com/mcp
  1. Claude: Add to Claude
  2. ChatGPT (Plus or higher): open Connectors → Advanced → turn on Developer mode → Create → paste the address, no authentication → Create.
  3. Cursor: install with one click. VS Code: install with one click.
Other apps and full steps
easy-composites-carbon-tube-6x4-tubeTube Ø6 OD × Ø4 ID × 1000 mmSTEP · STL
Let your AI pull this. Add https://xemstudio.com/mcp to Claude, ChatGPT, Cursor or any MCP client (free, no account, one minute) and it can look up exact sizes, mating fits and free STEP/STL from every chat.
Set it up →

Plain text: sheet.txt · JSON: /api/geometry?object=easy-composites-carbon-tube-6x4

Easy Composites 6 × 4 mm pultruded carbon tube, isometric render of a generated part
Render of easy-composites-carbon-tube-6x4-tube from the free STEP; not to scale.

Fits with

Questions

What tolerance does the 6 × 4 tube have?

±0.1 mm on OD and ID.
