Raspberry Pi Camera Module 3

What are the Raspberry Pi Camera Module 3 board and lens dimensions for a mount? · Modern device · basis: published mechanical drawing

Also called: pi camera 3, camera module 3, picam 3

Exact dimensions. Every file is drawn at true size with no tolerance added. The holes and pins that meet another part are listed below under Mating features, with the fit each joint needs; open those by your process's clearance before making the part. Mating features

length
25 mm
width
24 mm
holes
4 × Ø2.2 mm · 21 x 12.5 · M2

Notes

  • Four 2.2 mm holes on a 21 × 12.5 mm pattern (same as Camera Module 2); lens position differs between standard and wide variants.
  • Ribbon cable exits the bottom edge.

Mating features

Drawn at the exact size. Open press, slide, run and socket features by your process's clearance (tolerances by process); leave designed gaps and clamp fits as drawn.

featureexactmates withfitfiles
mounting holes4 × Ø2.2 on 21 × 12.5 (same as Camera Module 2)M2 screws; ribbon exits the bottom edgedesignedall

Where the files are

Other publishers' files are linked, not hosted. "verify" = check the license at the link before commercial use.

Raspberry Pi Ltd (official)Camera documentation (mechanical drawings)PDFCC BY-SA 4.0 (Raspberry Pi documentation) verify

Xem scan

File coming

No downloadable true-size file yet: the published figures do not fix the whole shape, and Xem never guesses a number. A measured scan is planned; request it and it moves up.

Votes decide what gets scanned first.

+1 for a scan of Raspberry Pi Camera Module 3

Your vote moves it up the list. Email is optional: only if you want one message when the file is ready.

Let your AI pull this. Add https://xemstudio.com/mcp to Claude, ChatGPT, Cursor or any MCP client (free, no account, one minute) and it can look up exact sizes, mating fits and free STEP/STL from every chat.
Set it up →

Plain text: sheet.txt · JSON: /api/geometry?object=raspberry-pi-camera-module-3

Schematic, not to scale.

Fits with

Questions

What are the Raspberry Pi Camera Module 3 dimensions in mm?

25 × 24 mm (length × width × height). Four 2.2 mm holes on a 21 × 12.5 mm pattern (same as Camera Module 2); lens position differs between standard and wide variants.

What is the Raspberry Pi Camera Module 3 mounting hole pattern?

4 × Ø2.2 mm on a 21 x 12.5 mm pattern, M2 screws.

Where is the official CAD for the Raspberry Pi Camera Module 3?

Raspberry Pi Ltd (official): Camera documentation (mechanical drawings) (PDF, CC BY-SA 4.0 (Raspberry Pi documentation)). Linked from the sheet; Xem Studio does not rehost it.
