SIRI REMOTE (3RD GENERATION)
What are the exact dimensions of the SIRI REMOTE (3RD GENERATION)? · Modern device · basis: Apple accessory dimensional drawing (developer.apple.com/accessories); numbers transcribed, geometry built by Xem Studio
Also called: SIRI REMOTE (3RD GENERATION) dimensions, SIRI REMOTE (3RD GENERATION) size, SIRI REMOTE (3RD GENERATION) dimensional drawing
Exact dimensions. True size, with no tolerance added.
- length
- 129.0 mm
- width
- 35.0 mm
- height
- 9.25 mm
Notes
- From Apple's published dimensional drawing for SIRI REMOTE (3RD GENERATION): 35 × 129 × 9.25 mm. The body file is built from the drawing's own numbers (corner-profile points, edge profile, camera and port positions): hollow it for a case, or subtract it (plus the case-cutouts file) to make a pocket, dock, tray or mount.
- Apple's notes for case makers: case thickness on the back 2.1 mm max; do not obstruct ports, cameras, flash or sensors; no metal contact; no magnets on the back except MagSafe.
- Sizes are exact nominal millimetres, true size: add your own clearance (for a printed case, typically a few tenths of a mm all round).
- From Apple's dimensional drawing for SIRI REMOTE (3RD GENERATION): the numbers below are as printed (Apple's drawing is linked, not copied). No body file: the drawing does not dimension the outline fully enough to build a true shape without guessing.
- Apple's notes for accessory makers: 1. NOTES 2-5 ARE INTENDED TO PREVENT SYSTEM PERFORMANCE DEGREDATION DURING NORMAL USE. STANDS OR HOLDERS NOT INTENDED TO BE INPLACE DURING NORMAL USE CAN DISREGARD BELOW NOTES.; 2 NO MATERIAL TO CONTACT, OVERLAP OR OBSTRUCT ANY PORTION OF IR / ANTENNA WINDOW. RECOMMENDED MIN. CLEARANCE 0.5MM.; 3 NO OBSTRUCTION OF MIC PORT. MIN. 1MM CLEARANCE TO OPENING.; 4 NO MATERIAL WITHIN 5MM OF CLICKPAD. NO METALS WITHIN 10MM OF CLICKPAD.; 5 NOT COMPATIBLE WITH APPLE REMOTE LOOP.; 6. SEE DETAIL 'A' FOR MINIMUM CLEARANCE REQUIRED AROUND CONNECTOR OPENING (13.65 x 6.85, CLEARANCE FOR CHARGE CABLE BODY)
SIRI REMOTE size chart
| parameter | value |
|---|---|
| width × length × thickness | 35 × 129 × 9.25 mm |
| overall (as printed) | 35.00 (bottom end view, width) |
| overall (as printed) | 129.00 (front view, length) |
| overall (as printed) | 9.25 (bottom end view, overall thickness at CL) |
| overall (as printed) | 2X 7.10 (end view, flat side wall height) |
| overall (as printed) | 4.03 (end view, connector centre from front face) |
| corner profile points (x from side, y from top) | (0, 9.17); (0, 7.67); (0.03, 6.67); (0.12, 5.67); (0.31, 4.69); (0.64, 3.75); (1.12, 2.87); (1.73, 2.08); (2.47, 1.41); (3.3, 0.86); (4.22, 0.46); (5.18, 0.2); (6.17, 0.06); (7.17, 0.01); (8.17, 0); (9.17, 0) |
| USB-C connector keep-out | 13.65 × 6.85 mm, centred on CL (17.50 from side) mm from the left edge |
| clickpad (touch ring) | Ø31.00 (note 2/4 keepout), centre button Ø17.50, 107.56 from bottom end to clickpad centre; 0.50 CLICKPAD PROUD |
| power button | Ø6.00, 7.00 right of CL, 129.00 line (top); 0.15 POWER BTN PROUD |
| mic port (note 3) | 1.0, 2.5, 10.50 (left of power, near top on CL) |
| front buttons | 4X Ø12.25; (14.75) (14.75) pitch; centres 84.62, 69.87, 55.12 from bottom; 5X 0.60 FRONT BTNS PROUD |
| volume rocker | 27.00 long, 11.75 (width / offset), centre right of CL 7.50 |
| bottom button column offsets | 7.50 left / 7.50 right of CL |
| Siri button (side) | 15.00 long, 3.60, 3.50; 0.60 SIRI BTN PROUD |
| IR / antenna window keepout (note 2) | 6.86 from top end; 0.50 ALL AROUND IR WINDOW; 0.80 ENCLOSURE RIM |
| charge connector (USB-C) | opening 3.01 x 8.80 (height x width), centre 4.03 from front face; DETAIL A connector clearance 13.65 x 6.85 (note 6) |
Where the files are
Other publishers' files are linked, not hosted. "verify" = check the license at the link before commercial use.
| Apple | SIRI REMOTE (3RD GENERATION) dimensional drawing (Accessory Design Guidelines) | Apple's terms; linked, not hosted |
Free files
★ Free files 1 parts. Generated by Xem Studio from the standard; threads are plain cylinders at major diameter. CC BY 4.0. index.json
Use this part in your AI. Your AI gets the exact sizes and files straight from Xem and can design a mount, case or adapter around it. Direct downloads here are limited to one file every 10 minutes; through your AI they are unlimited.
Connect Xem to your AI (free, no account, about a minute)
https://xemstudio.com/mcp- Claude: Add to Claude
- ChatGPT (Plus or higher): open Connectors → Advanced → turn on Developer mode → Create → paste the address, no authentication → Create.
- Cursor: install with one click. VS Code: install with one click.
| siri-remote-3rd-generation-body | SIRI REMOTE (3RD GENERATION) at true size: outline from Apple's corner-profile points, side profile, camera Sides drawn straight: the drawing does not dimension the edge profile. | STEP · STL |
https://xemstudio.com/mcp to Claude, ChatGPT, Cursor or any MCP client (free, no account, one minute) and it can look up exact sizes, mating fits and free STEP/STL from every chat.Plain text: sheet.txt · JSON: /api/geometry?object=siri-remote-3rd-generation

Questions
What are the SIRI REMOTE (3RD GENERATION) dimensions in mm?
129.0 × 35.0 × 9.25 mm (length × width × height). From Apple's published dimensional drawing for SIRI REMOTE (3RD GENERATION): 35 × 129 × 9.25 mm. The body file is built from the drawing's own numbers (corner-profile points, edge profile, camera and port positions): hollow it for a case, or subtract it (plus the case-cutouts file) to make a pocket, dock, tray or mount.
