Traxxas Slash 2WD kit (58014-4) parts list
What parts does the Traxxas Slash 2WD kit (58014-4) use, and what sizes are they? · Modern device · basis: Maker's manual / official spare-parts listing: part numbers and sizes as printed
Also called: Traxxas Slash 2WD kit (58014-4) part numbers, Traxxas Slash 2WD kit (58014-4) replacement parts, Traxxas Slash 2WD kit (58014-4) spare parts, Traxxas Slash 2WD kit (58014-4) parts diagram, Traxxas Slash 2WD kit (58014-4) exploded view, Traxxas Slash 2WD kit (58014-4) bearings, Traxxas Slash 2WD kit (58014-4) screw sizes, repuestos Traxxas Slash 2WD kit (58014-4), Traxxas Slash 2WD kit (58014-4) Er
Exact dimensions. True size, with no tolerance added.
- length
- 578 mm
- width
- 296 mm
- height
- 214 mm
Notes
- Every part number the maker publishes for the Traxxas Slash 2WD kit (58014-4) — 373 parts, 159 with sizes printed in the source (bearings, screws, pins, props, servos, motors, batteries…). Sizes are copied exactly as printed; "not published" means the source gives none.
- Files are the standard hardware in this list (bearings, screws, gears, props) at true size. Molded parts' shapes are not published, so they are not modelled; standard hardware links to its own pages.
- Use it to rebuild or re-print the vehicle: order the numbered parts, print the rest to the published sizes.
- From Traxxas's Slash 2WD unassembled kit 58014-4 parts list; the RTR 58034 shares the platform. The sheet mixes stock and option parts and gives no quantities.
Traxxas Slash 2WD kit (58014-4) parts list size chart
| part number | part | group | sizes (as printed) | qty | also fits |
|---|---|---|---|---|---|
| 3677 | Wheelie bar mount (1)/ hardware (black) | chassis | not published | not published | — |
| 3677A | Wheelie bar mount (1) / hardware (green) | chassis | not published | not published | — |
| 3677P | Wheelie bar mount (1) / hardware (pink) | chassis | not published | not published | — |
| 3677X | Wheelie bar mount (1)/ hardware (blue) | chassis | not published | not published | — |
| 3678 | Wheelie bar, assembled (black) (fits Slash, Bandit, Rustler®, Stampede® series) | chassis | not published | not published | traxxas-rustler-2wd |
| 3678A | Wheelie bar, assembled (green) (fits Slash, Bandit, Rustler®, Stampede® series) | chassis | not published | not published | traxxas-rustler-2wd |
| 3678P | Wheelie bar, assembled (pink) (fits Slash, Bandit, Rustler®, Stampede® series) | chassis | not published | not published | traxxas-rustler-2wd |
| 3678X | Wheelie bar, assembled (blue) (fits Slash, Bandit, Rustler®, Stampede® series) | chassis | not published | not published | traxxas-rustler-2wd |
| 4974 | Wheelie bar arm (1)/ connector (1)/ 3x12 SS (hex drive) (4) | chassis | ['3x12 SS (hex drive)'] | not published | — |
| 4976 | Wheels (4)/ axles (2) (for T-Maxx®/E-Maxx wheelie bar) | chassis | not published | not published | — |
| 5185 | Tires, rubber (2) (fits Traxxas® wheelie bar wheels) | chassis | not published | not published | — |
| 5186 | Wheels, aluminum (red-anodized) (2)/ 5x8mm ball bearings (4)/ axles (2)/ rubber tires (2) | chassis | ['5x8mm'] | not published | — |
| 5186A | Wheels, aluminum (blue-anodized) (2)/ 5x8mm ball bearings (4)/ axles (2)/ rubber tires (2) | chassis | ['5x8mm'] | not published | — |
| 5526 | Antenna crimp nut, aluminum (blue-anodized)/ antenna nut tools | chassis | not published | not published | — |
| 5526R | Antenna crimp nut, aluminum (red-anodized)/ antenna nut tools | chassis | not published | not published | — |
| 5624 | Box, receiver (sealed)/ foam pad/ silicone grease/ 3x8mm BCS (2)/ 2.5x8mm CS (2)/ 3x6mm BCS (2) | chassis | ['3x8mm BCS', '2.5x8mm CS', '3x6mm BCS'] | not published | — |
| 5625 | Seal kit, receiver box (includes o-ring, seals, and silicone grease) | chassis | not published | not published | — |
| 5822 | Chassis, Slash | chassis | not published | not published | — |
| 5822A | Chassis, Slash (black) | chassis | not published | not published | — |
| 5823 | Nerf bars, chassis (black) | chassis | not published | not published | — |
| 5827 | Hold down, battery/ hold down retainer/ battery post/ foam spacer/ angled body clip | chassis | not published | not published | — |
| 5827X | Hold down, battery/ hold down retainer/ battery post/ foam spacer/ angled body clip (allows for installation of taller, multi-cell batteries) | chassis | not published | not published | — |
| 5830 | Chassis conversion kit, low CG (Slash) | chassis | not published | not published | — |
| 5831 | Lower chassis, low CG (black) | chassis | not published | not published | — |
| 5831A | Lower chassis, low CG (blue) | chassis | not published | not published | — |
| 5831G | Lower chassis, low CG (grey) | chassis | not published | not published | — |
| 5832 | Chassis, low CG (black) | chassis | not published | not published | — |
| 5832A | Chassis, low CG (blue) | chassis | not published | not published | — |
| 5832G | Chassis, low CG (grey) | chassis | not published | not published | — |
| 5833 | Nerf bars, low CG (black) | chassis | not published | not published | — |
| 5833A | Nerf bars, low CG (blue) | chassis | not published | not published | — |
| 5833G | Nerf bars, low CG (grey) | chassis | not published | not published | — |
| 5835 | Bumper, front/ bumper mount, front (black) | chassis | not published | not published | — |
| 5835P | Bumper, front/ bumper mount, front (pink) | chassis | not published | not published | — |
| 5836 | Bumper, rear/ bumper mount, rear (black) | chassis | not published | not published | — |
| 5836P | Bumper, rear/ bumper mount, rear (pink) | chassis | not published | not published | — |
| 5837 | Skidplates, front & rear (black) | chassis | not published | not published | — |
| 1951 | Half shafts, long truck (external-splined (2) & internal-splined (2)/ metal U-joints (4) | suspension | not published | not published | — |
| 2530 | Bulkhead (front) (black) | suspension | not published | not published | — |
| 2530A | Bulkhead (front) (grey) | suspension | not published | not published | — |
| 2532 | Tie bar, fiberglass | suspension | not published | not published | — |
| 2555 | Suspension arms, (rear) (2) | suspension | not published | not published | — |
| 2555A | Suspension arms, blue, rear, heavy duty (2) | suspension | not published | not published | — |
| 2555G | Suspension arms, green, rear, heavy duty (2) | suspension | not published | not published | — |
| 2555L | Suspension arms, white, rear, heavy duty (2) | suspension | not published | not published | — |
| 2555R | Suspension arms, red, rear, heavy duty (2) | suspension | not published | not published | — |
| 2555T | Suspension arms, orange, rear, heavy duty (2) | suspension | not published | not published | — |
| 2555X | Suspension arms, black, rear, heavy duty (2) | suspension | not published | not published | — |
| 2640 | Suspension pins, 44mm (2) w/ e-clips | suspension | ['44mm'] | not published | — |
| 2753X | Stub axles, rear (2) | suspension | not published | not published | — |
| 3631 | Suspension arms (front) (2) | suspension | not published | not published | — |
| 3631A | Suspension arms, blue, front, heavy duty (2) | suspension | not published | not published | — |
| 3631G | Suspension arms, green, front, heavy duty (2) | suspension | not published | not published | — |
| 3631L | Suspension arms, white, front, heavy duty (2) | suspension | not published | not published | — |
| 3631R | Suspension arms, red, front, heavy duty (2) | suspension | not published | not published | — |
| 3631T | Suspension arms, orange, front, heavy duty (2) | suspension | not published | not published | — |
| 3631X | Suspension arms, black, front, heavy duty (2) | suspension | not published | not published | — |
| 3632 | Caster blocks (l&r) (30-degree) | suspension | ['30-degree'] | not published | — |
| 3632A | Caster blocks, 30-degree, blue-anodized 6061-T6 aluminum (left & right)/ suspension screw pin (2) | suspension | ['30-degree'] | not published | — |
| 3632G | Caster blocks, 30-degree, green-anodized 6061-T6 aluminum (left & right)/ suspension screw pin (2) | suspension | ['30-degree'] | not published | — |
| 3632P | Caster blocks, 30-degree, pink-anodized 6061-T6 aluminum (left & right)/ suspension screw pin (2) | suspension | ['30-degree'] | not published | — |
| 3632X | Caster blocks, 30-degree, red-anodized 6061-T6 aluminum (left & right)/ suspension screw pin (2) | suspension | ['30-degree'] | not published | — |
| 3637 | Axles (front) (2) | suspension | not published | not published | — |
| 3638 | Shock tower (rear) | suspension | not published | not published | — |
| 3639 | Shock tower (front) | suspension | not published | not published | — |
| 3640 | Suspension screw pin set, steel (hex drive) (requires part #2640 for a complete suspension pin set) (Bandit, Rustler®, Stampede®) | suspension | not published | not published | traxxas-rustler-2wd |
| 3643G | Camber links, front (TUBES green-anodized, 7075-T6 aluminum, stronger than titanium) (83mm) (2)/ rod ends (4)/ aluminum wrench (1) (#2579 3x15 BCS (4) required for installation) | suspension | ['3x15 BCS', '83mm'] | not published | — |
| 3643R | Camber links, front (TUBES red-anodized, 7075-T6 aluminum, stronger than titanium) (83mm) (2)/ rod ends (4)/ aluminum wrench (1) (#2579 3x15 BCS (4) required for installation) | suspension | ['3x15 BCS', '83mm'] | not published | — |
| 3643X | Camber links, front (TUBES blue-anodized, 7075-T6 aluminum, stronger than titanium) (83mm) (2)/ rod ends (4)/ aluminum wrench (1) (#2579 3x15 BCS (4) required for installation) | suspension | ['3x15 BCS', '83mm'] | not published | — |
| 3644 | Turnbuckles, camber link, 39mm (69mm center to center) (assembled with rod ends and hollow balls) (1 left, 1 right) (fits front & rear on Slash) | suspension | ['69mm center to center', '39mm'] | not published | — |
| 3644G | Camber links, rear (TUBES green-anodized 7075-T6 aluminum, stronger than titanium) (73mm) (2)/ rod ends (4)/ aluminum wrench (1) (#2579 3x15 BCS (4) required for installation) | suspension | ['3x15 BCS', '73mm'] | not published | — |
| 3644R | Camber links, rear (TUBES red-anodized, 7075-T6 aluminum, stronger than titanium) (73mm) (2)/ rod ends (4)/ aluminum wrench (1) (#2579 3x15 BCS (4) required for installation) | suspension | ['3x15 BCS', '73mm'] | not published | — |
| 3644X | Camber links, rear (TUBES blue-anodized, 7075-T6 aluminum, stronger than titanium) (73mm) (2)/ rod ends (4)/ aluminum wrench (1) (#2579 3x15 BCS (4) required for installation) | suspension | ['3x15 BCS', '73mm'] | not published | — |
| 3652A | Stub axle carriers, Rustler®/Stampede®/Bandit (2), 6061-T6 aluminum (blue-anodized)/ 5x11mm ball bearings (4) | suspension | ['5x11mm'] | not published | traxxas-rustler-2wd |
| 3652G | Stub axle carriers, Rustler®/Stampede®/Bandit (2), 6061-T6 aluminum (green-anodized)/ 5x11mm ball bearings (4) | suspension | ['5x11mm'] | not published | traxxas-rustler-2wd |
| 3652P | Stub axle carriers, Rustler®/Stampede®/Bandit (2), 6061-T6 aluminum (pink-anodized)/ 5x11mm ball bearings (4) | suspension | ['5x11mm'] | not published | traxxas-rustler-2wd |
| 3652X | Stub axle carriers, Rustler®/Stampede®/Bandit (2), 6061-T6 aluminum (red-anodized)/ 5x11mm ball bearings (4) | suspension | ['5x11mm'] | not published | traxxas-rustler-2wd |
| 3737 | Turnbuckle, aluminum (red-anodized), 39mm (1) (assembled w/rod ends)/hollow balls (2) (fits front & rear on Slash) | suspension | ['39mm'] | not published | — |
| 3737A | Turnbuckle, aluminum (blue-anodized), 39mm (1)(assembled w/rod ends)/hollow balls (2) (fits front & rear on Slash) | suspension | ['39mm'] | not published | — |
| 3739 | Screw pin set (Rustler®/ Bandit/ Stampede®) | suspension | not published | not published | traxxas-rustler-2wd |
| 3741A | Turnbuckles, aluminum (blue-anodized), camber links, front, 39mm (2), rear, 49mm (2) (assembled w/rod ends & hollow balls)/ wrench | suspension | ['39mm', '49mm'] | not published | — |
| 3741X | Turnbuckles, aluminum (red-anodized), camber links, front, 39mm (2), rear, 49mm (2) (assembled w/ rod ends & hollow balls)/wrench | suspension | ['39mm', '49mm'] | not published | — |
| 3752 | Stub axle carriers (2) (requires 5x11x4mm bearings) | suspension | ['5x11x4mm'] | not published | — |
| 1935 | Turnbuckles, 36mm (2) | steering | ['36mm'] | not published | — |
| 2742 | Rod ends, long (6)/ hollow ball connectors (6) | steering | not published | not published | — |
| 3139A | Turnbuckles, aluminum (blue-anodized), toe links, 59mm (2) (assembled w/ rod ends & hollow balls) (requires 5mm aluminum wrench #5477) | steering | ['59mm', '5mm'] | not published | — |
| 3139X | Turnbuckles, aluminum (red-anodized), toe links, 59mm (2) (assembled with rod ends & hollow balls) (requires 5mm aluminum wrench #5477) | steering | ['59mm', '5mm'] | not published | — |
| 3636A | Steering blocks, Rustler®/Stampede®/Bandit (2), 6061-T6 aluminum (blue-anodized)/ 5x11mm ball bearings (4) | steering | ['5x11mm'] | not published | traxxas-rustler-2wd |
| 3636G | Steering blocks, Rustler®/Stampede®/Bandit (2), 6061-T6 aluminum (green-anodized)/ 5x11mm ball bearings (4) | steering | ['5x11mm'] | not published | traxxas-rustler-2wd |
| 3636P | Steering blocks, Rustler®/Stampede®/Bandit (2), 6061-T6 aluminum (pink-anodized)/ 5x11mm ball bearings (4) | steering | ['5x11mm'] | not published | traxxas-rustler-2wd |
| 3636X | Steering blocks, Rustler®/Stampede®/Bandit (2), 6061-T6 aluminum (red-anodized)/ 5x11mm ball bearings (4) | steering | ['5x11mm'] | not published | traxxas-rustler-2wd |
| 3736 | Steering blocks, left & right (2) (requires 5x11x4mm bearings) | steering | ['5x11x4mm'] | not published | — |
| 3743 | Steering bellcranks (l&r)/ draglink | steering | not published | not published | — |
| 3743A | Steering bellcranks, drag link (blue-anodized 6061-T6 aluminum)/ 5x8mm ball bearings (4)/ hardware (assembled) | steering | ['5x8mm'] | not published | — |
| 3743G | Steering bellcranks, drag link (green-anodized 6061-T6 aluminum)/ 5x8mm ball bearings (4)/ hardware (assembled) | steering | ['5x8mm'] | not published | — |
| 3743P | Steering bellcranks, drag link (pink-anodized 6061-T6 aluminum)/ 5x8mm ball bearings (4)/ hardware (assembled) | steering | ['5x8mm'] | not published | — |
| 3743X | Steering bellcranks, drag link (red-anodized 6061-T6 aluminum)/ 5x8mm ball bearings (4)/ hardware (assembled) | steering | ['5x8mm'] | not published | — |
| 3744 | Servo saver w/adapters | steering | not published | not published | — |
| 3745 | Turnbuckles, toe link, 59mm (78mm center to center) (2) (assembled with rod ends and hollow balls) | steering | ['78mm center to center', '59mm'] | not published | — |
| 6845X | Steering bellcranks/ servo saver/ servo saver spring/ servo spring retainer/servo horn, steering | steering | not published | not published | — |
| 1552 | Motor screws (3x8mm hex cap) (6)/washers (6)/ wrench | drivetrain | ['3x8mm'] | not published | — |
| 1647 | Silicone grease | drivetrain | not published | not published | — |
| 1918 | Gear, 18-T pinion (48-pitch) / set screw | drivetrain | ['18-T pinion', '48-pitch'] | not published | — |
| 1953 | Half shaft pro-pack (internal-splined (6)/ external-splined (6) (plastic shafts only) | drivetrain | not published | not published | — |
| 2380 | Differential, complete (fits 1/10-scale 2WD Rustler®, Bandit, Stampede®, Slash) | drivetrain | not published | not published | traxxas-rustler-2wd |
| 2381X | Main diff with steel ring gear/ side cover plate/ screws (Bandit, Stampede®, Rustler®) | drivetrain | not published | not published | traxxas-rustler-2wd |
| 2382 | Planet gears (4)/ planet shafts (4)/ sun gears (2)/sun gear alignment shaft (1) all hardened steel | drivetrain | not published | not published | — |
| 2388X | Planetary gear differential with steel ring gear (complete) (fits Bandit, Stampede®, Rustler®) | drivetrain | not published | not published | traxxas-rustler-2wd |
| 2416 | Gear, 16-T pinion (48-pitch) / set screw | drivetrain | ['16-T pinion', '48-pitch'] | not published | — |
| 2419 | Gear, 19-T pinion (48-pitch) / set screw | drivetrain | ['19-T pinion', '48-pitch'] | not published | — |
| 2423 | Gear, 23-T pinion (48-pitch) / set screw | drivetrain | ['23-T pinion', '48-pitch'] | not published | — |
| 2426 | Gear, 26-T pinion (48-pitch)/set screw | drivetrain | ['26-T pinion', '48-pitch'] | not published | — |
| 2431 | Gear, 31-T pinion (48-pitch) / set screw | drivetrain | ['31-T pinion', '48-pitch'] | not published | — |
| 2554 | Screws, 3x6mm cap-head machine (hex drive) (6) | drivetrain | ['3x6mm cap-head machine (hex drive)'] | not published | — |
| 3195 | Top drive gear, steel (22-tooth) | drivetrain | ['22-tooth'] | not published | — |
| 3691 | Gearbox halves (l&r) (black) w/ idler gear shaft | drivetrain | not published | not published | — |
| 3691A | Gearbox halves (l&r) (grey) w/ idler gear shaft | drivetrain | not published | not published | — |
| 3695 | Transmission, complete (fits 1/10-scale 2WD Rustler®, Bandit, Stampede®, Slash) | drivetrain | not published | not published | traxxas-rustler-2wd |
| 3696 | Idler gear, steel (30-tooth) | drivetrain | ['30-tooth'] | not published | — |
| 3790 | Gear adapter, fixed | drivetrain | not published | not published | — |
| 3792 | Cover, gear/ rubber gear cover plug/ 3x6 RM (2) | drivetrain | ['3x6 RM'] | not published | — |
| 3793 | Input shaft (slipper shaft) / spring pin | drivetrain | not published | not published | — |
| 4628R | Differential output yokes, black (2)/ 3x5mm countersunk screws (2)/ screw pin (2) | drivetrain | ['3x5mm countersunk screws'] | not published | — |
| 4628X | Differential output yokes, hardened steel (w/ U-joints) (2) | drivetrain | not published | not published | — |
| 4683 | Spur gear, 83-tooth (48-pitch) (for models with Torque-Control slipper clutch) | drivetrain | ['83-tooth', '48-pitch'] | not published | — |
| 4686 | Spur gear, 86-tooth (48-pitch) (for models with Torque-Control slipper clutch) | drivetrain | ['86-tooth', '48-pitch'] | not published | — |
| 4690 | Spur gear, 90-tooth (48-pitch) (for models with Torque-Control slipper clutch) | drivetrain | ['90-tooth', '48-pitch'] | not published | — |
| 4725 | Gear, pinion (25-tooth) (48-pitch) / set screw | drivetrain | ['25-tooth', '48-pitch'] | not published | — |
| 4728 | Gear, pinion (28-tooth) (48-pitch)/ set screw | drivetrain | ['28-tooth', '48-pitch'] | not published | — |
| 5148 | Grease, white lithium | drivetrain | not published | not published | — |
| 5169 | Screws, 2.6x8mm countersunk machine (6) | drivetrain | ['2.6x8mm countersunk machine'] | not published | — |
| 5552X | Rebuild kit, slipper clutch (steel disc/ friction pads (3)/ spring (2)/ pin/ 4.0mm NL (1)/ 5.0mm NL (1)) | drivetrain | ['4.0mm NL', '5.0mm NL'] | not published | — |
| 5556 | Slipper pressure plate & hub (aluminum alloy) | drivetrain | not published | not published | — |
| 6750 | Half shaft, external splined (steel-spline constant-velocity) (1) | drivetrain | not published | not published | — |
| 6751 | Half shaft, internal splined (steel-spline constant-velocity) (1) | drivetrain | not published | not published | — |
| 6753 | Stub axle, rear, 5mm (steel-splined constant-velocity driveshaft) (1) | drivetrain | ['5mm'] | not published | — |
| 6757 | Rebuild kit, steel-splined constant-velocity driveshafts (includes pins, dustboots, lube, and hardware) | drivetrain | not published | not published | — |
| 6828X | Differential output yokes, heavy duty (2)/ screw pin (2) | drivetrain | not published | not published | — |
| 6850X | Half shafts, heavy duty (external splined (2)/ internal splined (2))/ metal u-joints (4) | drivetrain | not published | not published | — |
| 6852R | Driveshafts, rear, steel-spline constant-velocity (complete assembly) (2) | drivetrain | not published | not published | — |
| 6852X | Driveshaft assembly, rear, heavy duty (1) (left or right) (fully assembled, ready to install)/ screw pin (1) | drivetrain | not published | not published | — |
| 6853X | Stub axles, rear, heavy duty (2)/pins (2) | drivetrain | not published | not published | — |
| 9052X | Driveshafts, rear, steel-spline constant-velocity (complete assembly) (2) | drivetrain | not published | not published | — |
| 9053X | Stub axle, rear, steel-splined constant velocity (1) | drivetrain | not published | not published | — |
| 9055X | Half shaft, external splined (steel-spline constant velocity) (1) | drivetrain | not published | not published | — |
| 9056X | Half shaft, internal splined (steel-spline constant velocity) (1) | drivetrain | not published | not published | — |
| 9057X | Differential output shafts, steel-splined constant-velocity (2) | drivetrain | not published | not published | — |
| 9058X | Rebuild kit, steel-splined constant-velocity driveshafts (includes pins and hardware for one axle shaft) | drivetrain | not published | not published | — |
| 9059X | Cross pin (2)/ drive pin (2) (repairs 1 axle shaft) | drivetrain | not published | not published | — |
| 1664 | Shock shafts, steel, chrome finish (long) (2) | shocks | not published | not published | — |
| 1664T | Shock shafts, hardened steel, titanium nitride coated (long) (2) | shocks | not published | not published | — |
| 1666 | Silicone shock oil (30 wt) | shocks | ['30 wt'] | not published | — |
| 1765 | Silicone diaphragms (4) | shocks | not published | not published | — |
| 1942 | Rod ends (16 long & 4 short)/ hollow ball connectors (18)/ ball screws (2) | shocks | not published | not published | — |
| 2362 | Rebuild kit, Ultra shocks (for 2 shocks) | shocks | not published | not published | — |
| 2458 | Springs, front (black) (2) | shocks | not published | not published | — |
| 2458A | Springs, front (white) (2) | shocks | not published | not published | — |
| 2458P | Springs, front (pink) (2) | shocks | not published | not published | — |
| 2656 | Shock shafts, steel, chrome finish (xx-long) (2) | shocks | not published | not published | — |
| 2656T | Shock shafts, hardened steel, titanium nitride coated (xx-long) (2) | shocks | not published | not published | — |
| 2660 | Big Bore shocks (long) (hard-anodized & PTFE-coated T6 aluminum) (assembled with TiN shafts) w/o springs (front) (2) | shocks | not published | not published | — |
| 2662 | Big Bore shocks (XX-long) (hard-anodized & PTFE-coated T6 aluminum) (assembled with TiN shafts) w/o springs (rear) (2) | shocks | not published | not published | — |
| 2664 | Big Bore shock cylinder (long) (1) | shocks | not published | not published | — |
| 2666 | Big Bore shock cylinder (XX-long) (1) | shocks | not published | not published | — |
| 2667 | Shock caps, aluminum (Big Bore Shocks) (2) | shocks | not published | not published | — |
| 2668 | Spring retainers, upper & lower (2)/ spring pre-load spacers: 1mm (4)/ 1.5mm (2)/ 2mm (2)/ 4mm (2)/ 8mm (2) (Big Bore Shocks) | shocks | ['1mm', '1.5mm', '2mm', '4mm', '8mm'] | not published | — |
| 2669 | Piston head set (2-hole (2)/ 3-hole (2))/ shock mounting bushings & washers (2) (Big Bore Shocks) | shocks | not published | not published | — |
| 3757 | Springs, rear (black) (2) | shocks | not published | not published | — |
| 3757A | Springs, rear (green) (2) | shocks | not published | not published | — |
| 3757P | Springs, rear (pink) (2) | shocks | not published | not published | — |
| 3757T | Springs, rear (blue) (2) | shocks | not published | not published | — |
| 3757X | Springs, rear (white) (2) | shocks | not published | not published | — |
| 3760 | Ultra Shocks (black) (long) (complete w/ spring pre-load spacers & springs) (front) (2) | shocks | not published | not published | — |
| 3760A | Ultra Shocks (grey) (long) (complete w/ spring pre-load spacers & springs) (2) | shocks | not published | not published | — |
| 3762 | Ultra Shocks (black) (xx-long) (complete w/ spring pre-load spacers & springs) (rear) (2) | shocks | not published | not published | — |
| 3762A | Ultra Shocks (grey) (xx-long) (complete w/ spring pre-load spacers & springs) (rear) (2) | shocks | not published | not published | — |
| 3765A | Body, Ultra Shock(s) (long) (grey) (2) | shocks | not published | not published | — |
| 3766A | Body, Ultra Shock(s) (XXL) (grey) (2) | shocks | not published | not published | — |
| 3767 | Shock caps (2)/ shock bottoms (2) | shocks | not published | not published | — |
| 3767A | Shock caps, aluminum (blue-anodized) (4) (fits all Ultra Shocks) | shocks | not published | not published | — |
| 3767G | Shock caps, aluminum (green-anodized) (4) (fits all Ultra Shocks) | shocks | not published | not published | — |
| 3767P | Shock caps, aluminum (pink-anodized) (4) (fits all Ultra Shocks) | shocks | not published | not published | — |
| 3767X | Shock caps, aluminum (red-anodized) (4) (fits all Ultra Shocks) | shocks | not published | not published | — |
| 3768 | Spring retainers, upper & lower (2)/ piston head set (2-hole (2)/ 3-hole (2)) | shocks | not published | not published | — |
| 3769 | Spring pre-load spacers: 1mm (4)/ 2mm (2)/ 4mm (2)/ 8mm (2) | shocks | ['1mm', '2mm', '4mm', '8mm'] | not published | — |
| 4957 | Springs, red (for Ultra Shocks only) (2.5 rate) (f/r) (2) | shocks | not published | not published | — |
| 5857 | Springs, front (white) (progressive rate) (2) | shocks | not published | not published | — |
| 5857P | Springs, front (pink) (progressive rate) (2) | shocks | not published | not published | — |
| 5858 | Springs, rear (white) (progressive rate) (2) | shocks | not published | not published | — |
| 5858P | Springs, rear (pink) (progressive rate) (2) | shocks | not published | not published | — |
| 5859 | Springs, rear (white) (progressive rate) (2) (fits #5862 aluminum Big Bore shocks) | shocks | not published | not published | — |
| 5860 | Springs, front (white) (progressive rate) (2) (fits #5862 aluminum Big Bore shocks) | shocks | not published | not published | — |
| 5862 | Big Bore shocks (hard-anodized & PTFE-coated T6 aluminum) (assembled with TiN shafts and springs) (front & rear) (4) | shocks | not published | not published | — |
| 8361 | Shock caps (black) (4) (assembled with hollow balls) | shocks | not published | not published | — |
| 1654 | Wheel hubs, hex (rear) (2)/ stub axle pins (2) | wheels & tires | not published | not published | — |
| 3654 | Wheel hubs, hex (tall offset, Rustler®/Stampede® front) (2)/ axle pins (2.5x10mm) (2) | wheels & tires | ['2.5x10mm'] | not published | traxxas-rustler-2wd |
| 5353 | Wheel nuts, splined, 17mm (blue-anodized) (4) | wheels & tires | ['17mm'] | not published | — |
| 5480X | Wheel wrench, splined, 17mm | wheels & tires | ['17mm'] | not published | — |
| 5853X | Wheel hubs only: splined 17mm (short and long); blue-anodized wheel nuts; hub retainers; axle pins; 5mm wrench | wheels & tires | ['17mm', '5mm'] | not published | — |
| 5854 | Hub retainer, 17mm hubs, M4 X 0.7 (4) (use with #5853X, #6856X, #6469) | wheels & tires | ['M4 X 0.7', '17mm'] | not published | — |
| 5863 | SCT black/orange beadlock wheels; dual profile (2.2" outer, 3.0" inner); SCT off-road tires; foam inserts; qty 2; 4WD f/r, 2WD rear; TSM rated | wheels & tires | ['2.2" outer, 3.0" inner'] | not published | traxxas-slash-4x4-vxl |
| 5864 | Tire & wheel assy, glued (SCT black, orange beadlock wheels, SCT off-road racing tires, foam inserts) (2) (2WD front) | wheels & tires | not published | not published | — |
| 5865 | SCT chrome, green beadlock wheel; BFG KM2 tire; foam inserts; qty 2; 2WD front only | wheels & tires | not published | not published | — |
| 5866 | Wheels, SCT, chrome, green beadlock style, dual profile (2.2" outer, 3.0" inner) (2) (2WD front only) | wheels & tires | ['2.2" outer, 3.0" inner'] | not published | — |
| 5867 | SCT chrome red beadlock wheels; BFG KM2 tires; foam inserts; qty 2; 4WD front/rear, 2WD rear only | wheels & tires | not published | not published | traxxas-slash-4x4-vxl |
| 5868 | Wheels, SCT chrome, red beadlock style, dual profile (2.2” outer, 3.0” inner) (4WD front/rear, 2WD rear only) (2) | wheels & tires | ['2.2” outer, 3.0” inner'] | not published | traxxas-slash-4x4-vxl |
| 5868X | Wheels, SCT black, orange beadlock style, dual profile (2.2" outer, 3.0" inner) (4WD f/r, 2WD rear) (2) | wheels & tires | ['2.2" outer, 3.0" inner'] | not published | traxxas-slash-4x4-vxl |
| 5869 | SCT chrome red beadlock wheels; BFG KM2 tires; foam inserts; qty 2; 2WD front | wheels & tires | not published | not published | — |
| 5870 | Wheels, SCT chrome, red beadlock style, dual profile (2.2” outer, 3.0” inner) (2WD front) (2) | wheels & tires | ['2.2” outer, 3.0” inner'] | not published | — |
| 5870X | Wheels, SCT black, orange beadlock style, dual profile (2.2" outer, 3.0" inner) (2WD front) (2) | wheels & tires | ['2.2" outer, 3.0" inner'] | not published | — |
| 5871 | Tires, off-road racing, SCT dual profile 4.3x1.7- 2.2/3.0" (2)/ foam inserts (2) | wheels & tires | ['4.3x1.7- 2.2/3.0"'] | not published | — |
| 5871R | Tires, ultra-soft, S1 compound for off-road racing, SCT dual profile 4.3x1.7- 2.2/3.0" (2)/ foam inserts (2) | wheels & tires | ['4.3x1.7- 2.2/3.0"'] | not published | — |
| 5872 | Wheels, SCT satin chrome, beadlock style, dual profile (2.2" outer, 3.0" inner) (4WD front/rear, 2WD rear only) | wheels & tires | ['2.2" outer, 3.0" inner'] | not published | traxxas-slash-4x4-vxl |
| 5872A | Wheels, SCT satin chrome, red beadlock style, dual profile (2.2" outer, 3.0" inner) (4WD front/rear, 2WD rear only) (2) | wheels & tires | ['2.2" outer, 3.0" inner'] | not published | traxxas-slash-4x4-vxl |
| 5872X | Wheels only: SCT satin chrome, black beadlock style; dual profile (2.2" outer, 3.0" inner); qty 2; 4WD f/r, 2WD rear only | wheels & tires | ['2.2" outer, 3.0" inner'] | not published | traxxas-slash-4x4-vxl |
| 5873 | SCT satin chrome beadlock wheels; SCT off-road tires; foam inserts; qty 2; 4WD f/r, 2WD rear only; TSM rated | wheels & tires | not published | not published | traxxas-slash-4x4-vxl |
| 5873A | SCT satin chrome, red beadlock wheels; SCT off-road tires; foam inserts; qty 2; 4WD front/rear, 2WD rear only | wheels & tires | not published | not published | traxxas-slash-4x4-vxl |
| 5873R | SCT satin chrome red beadlock wheels; ultra-soft S1 SCT tires; inserts; qty 2; 2WD rear, 4WD f/r | wheels & tires | not published | not published | traxxas-slash-4x4-vxl |
| 5873X | SCT satin chrome, black beadlock wheels; SCT off-road tires; foam inserts; qty 2; 4WD f/r, 2WD rear only | wheels & tires | not published | not published | traxxas-slash-4x4-vxl |
| 5874 | Wheels, SCT satin chrome, beadlock style, dual profile (2.2" outer, 3.0" inner) (2WD front) | wheels & tires | ['2.2" outer, 3.0" inner'] | not published | — |
| 5874A | Wheels, SCT satin chrome, red beadlock style, dual profile (2.2" outer, 3.0" inner) (2WD front) (2) | wheels & tires | ['2.2" outer, 3.0" inner'] | not published | — |
| 5874X | Wheels, SCT satin chrome, black beadlock style, dual profile (2.2” outer, 3.0” inner) (2WD front) (2) | wheels & tires | ['2.2” outer, 3.0” inner'] | not published | — |
| 5875 | SCT satin chrome beadlock wheels; SCT off-road tires; foam inserts; qty 2; 2WD front | wheels & tires | not published | not published | — |
| 5875X | SCT satin chrome, black beadlock wheels; SCT off-road tires; foam inserts; qty 2; 2WD front | wheels & tires | not published | not published | — |
| 5876 | Wheels, SCT Split-Spoke, satin chrome, black beadlock style, dual profile (2.2" outer, 3.0" inner) (2WD front) (2) | wheels & tires | ['2.2" outer, 3.0" inner'] | not published | — |
| 5876A | Wheels, SCT Split-Spoke, chrome, red beadlock style, dual profile (2.2" outer, 3.0" inner) (2WD front) (2) | wheels & tires | ['2.2" outer, 3.0" inner'] | not published | — |
| 5877 | SCT Split-Spoke, satin chrome, black beadlock wheels; BFG KM2 tires; foam inserts; qty 2; 2WD front | wheels & tires | not published | not published | — |
| 5877A | SCT Split-Spoke, chrome red beadlock wheels; BFG KM2 tires; foam inserts; qty 2; 2WD front | wheels & tires | not published | not published | — |
| 5877R | S1 ultra-soft compound; SCT Split-Spoke chrome, red beadlock wheels; BFG KM2 tires; qty 2; 2WD front | wheels & tires | not published | not published | — |
| 5878 | SCT satin chrome, black beadlock wheels; BFG KM2 tires; foam inserts; qty 2; 4WD front/rear, 2WD rear only | wheels & tires | not published | not published | traxxas-slash-4x4-vxl |
| 5880 | Glued assembly; SCT satin chrome, black beadlock wheels; Kumho tires; foam inserts; qty 2; 4WD front/rear, 2WD rear only | wheels & tires | not published | not published | traxxas-slash-4x4-vxl |
| 5880X | Glued assembly; SCT satin chrome beadlock wheels; Kumho tires; foam inserts; qty 2; 4WD front/rear, 2WD rear only | wheels & tires | not published | not published | traxxas-slash-4x4-vxl |
| 5881 | SCT satin chrome, black beadlock wheels; Kumho tires; foam inserts; qty 2; 2WD front | wheels & tires | not published | not published | — |
| 5881X | SCT satin chrome beadlock wheels; Kumho tires; foam inserts; qty 2; 2WD front | wheels & tires | not published | not published | — |
| 5882 | Glued assembly; SCT Split-Spoke satin chrome, black beadlock wheels; Kumho tires; foam inserts; qty 2; 2WD front | wheels & tires | not published | not published | — |
| 5882R | S1 ultra-soft compound; SCT Split-Spoke satin chrome, black beadlock wheels; Kumho tires; foam inserts; qty 2; 2WD front | wheels & tires | not published | not published | — |
| 5883 | SCT Split-Spoke, black, satin chrome beadlock wheels; BFG KM2 tire; foam inserts; qty 2; 4WD f/r, 2WD rear | wheels & tires | not published | not published | traxxas-slash-4x4-vxl |
| 5883A | Glued tire & wheel assembly; SCT Split-Spoke black wheels with blue beadlock; BFG Mud-Terrain KM2 tire; inserts; qty 2; 4WD f/r, 2WD rear | wheels & tires | not published | not published | traxxas-slash-4x4-vxl |
| 5884 | Wheels, SCT Split-Spoke, black, satin chrome beadlock style, dual profile (2.2" outer, 3.0" inner) (4WD f/r, 2WD rear) (2) | wheels & tires | ['2.2" outer, 3.0" inner'] | not published | traxxas-slash-4x4-vxl |
| 5884A | Wheels, SCT Split-Spoke, black, blue beadlock style, dual profile (2.2" outer, 3.0" inner) (4WD f/r, 2WD rear) (2) | wheels & tires | ['2.2" outer, 3.0" inner'] | not published | traxxas-slash-4x4-vxl |
| 5885 | SCT Split-Spoke, black, satin chrome beadlock wheels; BFG KM2 tires; foam inserts; qty 2; 2WD front | wheels & tires | not published | not published | — |
| 5885A | Glued tire & wheel assembly; SCT Split-Spoke black wheels with blue beadlock; BFG Mud-Terrain KM2 tires; inserts; qty 2; 2WD front | wheels & tires | not published | not published | — |
| 5886 | Wheels, SCT Split-Spoke, black, satin chrome beadlock style, dual profile (2.2" outer, 3.0" inner) (2WD front) (2) | wheels & tires | ['2.2" outer, 3.0" inner'] | not published | — |
| 5886A | Wheels, SCT Split-Spoke, black, blue beadlock style, dual profile (2.2" outer, 3.0" inner) (2WD front) (2) | wheels & tires | ['2.2" outer, 3.0" inner'] | not published | — |
| 5891 | SCT Split-Spoke satin chrome beadlock wheels; paddle tires; foam inserts; qty 2; 4WD f/r, 2WD rear only; TSM rated | wheels & tires | not published | not published | traxxas-slash-4x4-vxl |
| 6870 | Tires, Kumho (dual profile 4.3x1.7- 2.2/3.0") (2)/ foam inserts (2) | wheels & tires | ['4.3x1.7- 2.2/3.0"'] | not published | — |
| 6870R | Tires, Kumho, ultra-soft (S1 off-road racing compound) (dual profile 4.3x1.7- 2.2/3.0") (2)/ foam inserts (2) | wheels & tires | ['4.3x1.7- 2.2/3.0"'] | not published | — |
| 6871 | Tires, BFGoodrich® Mud-Terrain T/A® KM2 (dual profile 4.3x1.7- 2.2/3.0") (2)/ foam inserts (2) | wheels & tires | ['4.3x1.7- 2.2/3.0"'] | not published | — |
| 6871R | Tires only: BFG Mud-Terrain KM2, ultra-soft S1 compound; dual profile 4.3x1.7-2.2/3.0"; qty 2 with 2 foam inserts | wheels & tires | ['4.3x1.7-2.2/3.0"'] | not published | — |
| 6872 | Wheels only: SCT Split-Spoke satin chrome, black beadlock style; dual profile; qty 2; 4WD front/rear, 2WD rear only | wheels & tires | not published | not published | traxxas-slash-4x4-vxl |
| 6872A | Wheels only: SCT Split-Spoke chrome, red beadlock style; dual profile; qty 2; 4WD front/rear, 2WD rear | wheels & tires | not published | not published | traxxas-slash-4x4-vxl |
| 6872X | Wheels only: SCT Split-Spoke chrome, green beadlock style; dual profile; qty 2; 4WD front/rear, 2WD rear | wheels & tires | not published | not published | traxxas-slash-4x4-vxl |
| 6873 | SCT Split-Spoke satin chrome, black beadlock wheels; BFG KM2 tires; foam inserts; qty 2; 4WD f/r, 2WD rear; TSM rated | wheels & tires | not published | not published | traxxas-slash-4x4-vxl |
| 6873A | SCT Split-Spoke chrome, red beadlock wheels; BFG KM2 tires; foam inserts; qty 2; 4WD f/r, 2WD rear | wheels & tires | not published | not published | traxxas-slash-4x4-vxl |
| 6873R | S1 ultra-soft compound; SCT Split-Spoke chrome, red beadlock wheels; BFG KM2 tires; foam inserts; qty 2; 4WD f/r, 2WD rear | wheels & tires | not published | not published | traxxas-slash-4x4-vxl |
| 6873X | S1 ultra-soft compound; SCT Split-Spoke satin chrome, black beadlock wheels; BFG Mud-Terrain tires; foam inserts; qty 2; 4WD f/r, 2WD rear only | wheels & tires | not published | not published | traxxas-slash-4x4-vxl |
| 6874 | SCT Split-Spoke satin chrome, black beadlock wheels; Kumho tires; foam inserts; qty 2; 4WD front/rear, 2WD rear only | wheels & tires | not published | not published | traxxas-slash-4x4-vxl |
| 6874R | S1 ultra-soft compound; SCT Split-Spoke satin chrome, black beadlock wheels; Kumho tires; foam inserts; qty 2; 4WD f/r, 2WD rear only | wheels & tires | not published | not published | traxxas-slash-4x4-vxl |
| 6875 | Wheels, SCT, chrome, green beadlock style, dual profile (2.2" outer, 3.0" inner) (2) (4WD front/rear, 2WD rear only) | wheels & tires | ['2.2" outer, 3.0" inner'] | not published | traxxas-slash-4x4-vxl |
| 6876 | SCT chrome, green beadlock wheel; BFG KM2 tire; foam inserts; qty 2; 4WD front/rear, 2WD rear only | wheels & tires | not published | not published | traxxas-slash-4x4-vxl |
| 2072A | Gear set (for 2070, 2075 servos) | electronics | not published | not published | — |
| 2074 | Servo case/gaskets (for 2056 and 2075 waterproof servos) | electronics | not published | not published | — |
| 2075 | Servo, digital high-torque (ball bearing), waterproof | electronics | not published | not published | — |
| 2075R | Servo, digital high-speed, metal gear (ball bearing), waterproof | electronics | not published | not published | — |
| 2075X | Servo, digital high-torque, metal gear (ball bearing), waterproof | electronics | not published | not published | — |
| 2250 | Servo, digital high-torque 330 coreless, metal gear (ball bearing), waterproof | electronics | not published | not published | — |
| 2251 | Servo case, plastic (top, middle, bottom)/ gaskets/ hardware (for 2250, 2255 servos) | electronics | not published | not published | — |
| 2252 | Gear set, metal (for 2250, 2255 servos) | electronics | not published | not published | — |
| 2253 | Servo case, aluminum (red-anodized) (middle) (for 2255 servo) | electronics | not published | not published | — |
| 2254 | Servo case, aluminum (blue-anodized) (middle) (for 2250 servo) | electronics | not published | not published | — |
| 2255 | Servo, digital high-torque 400 brushless, metal gear (ball bearing), waterproof | electronics | not published | not published | — |
| 2260 | BEC assembly (complete) | electronics | not published | not published | — |
| 2842X | 5000mAh 7.4v 2-Cell 25C LiPo Battery | electronics | ['5000mAh', '7.4v', '2-Cell', '25C'] | not published | — |
| 2843X | 5800mAh 7.4v 2-Cell 25C LiPo Battery | electronics | ['5800mAh', '7.4v', '2-Cell', '25C'] | not published | — |
| 2869X | 7600mAh 7.4v 2-Cell 25C LiPo Battery | electronics | ['7600mAh', '7.4v', '2-Cell', '25C'] | not published | — |
| 2923X | Battery, Power Cell, 3000mAh (NiMH, 7-C flat, 8.4V) | electronics | ['3000mAh', '8.4V'] | not published | — |
| 2926X | Battery, Power Cell, 3000mAh (NiMH, 7-C hump, 8.4V) | electronics | ['3000mAh', '8.4V'] | not published | — |
| 2940X | Battery, Series 3 Power Cell, 3300mAh (NiMH, 7-C flat, 8.4V) | electronics | ['3300mAh', '8.4V'] | not published | — |
| 2941X | Battery, Series 3 Power Cell, 3300mAh (NiMH, 7-C hump, 8.4V) | electronics | ['3300mAh', '8.4V'] | not published | — |
| 2950X | Battery, Series 4 Power Cell, 4200mAh (NiMH, 7-C flat, 8.4V) | electronics | ['4200mAh', '8.4V'] | not published | — |
| 2951X | Battery, Series 4 Power Cell, 4200mAh (NiMH, 7-C hump, 8.4V) | electronics | ['4200mAh', '8.4V'] | not published | — |
| 2960X | Battery, Series 5 Power Cell, 5000mAh (NiMH, 7-C flat, 8.4V) | electronics | ['5000mAh', '8.4V'] | not published | — |
| 2961X | Battery, Series 5 Power Cell, 5000mAh (NiMH, 7-C hump, 8.4V) | electronics | ['5000mAh', '8.4V'] | not published | — |
| 3018R | XL-5 Electronic Speed Control, waterproof (land version, low-voltage detection, fwd/rev/brake) | electronics | not published | not published | — |
| 3350R | Velineon® VXL-3s Brushless Power System, waterproof (includes VXL-3s waterproof ESC, Velineon 3500 motor, and speed control mounting plate (part #3725R)) | electronics | not published | not published | — |
| 3351R | Motor, Velineon® 3500, brushless (assembled with 12-gauge wire and gold-plated bullet connectors) | electronics | ['12-gauge'] | not published | — |
| 3355R | Velineon® VXL-3s Electronic Speed Control, waterproof (brushless) (fwd/rev/brake) | electronics | not published | not published | — |
| 3785 | Motor, Titan® 12T (12-Turn, 550 size) | electronics | ['12T', '550 size', '12-Turn'] | not published | — |
| 6507R | TQi 2.4 GHz High Output radio system, 4-channel with Traxxas Link™ Wireless Module, TSM (4-ch transmitter, 5-ch micro receiver) | electronics | ['4-channel'] | not published | — |
| 6509R | TQi 2.4 GHz High Output radio system, 2-channel, Traxxas Link™ enabled, TSM (2-ch transmitter, 5-ch micro receiver) | electronics | ['2-channel'] | not published | — |
| 6511 | Traxxas Link™ Wireless Module | electronics | not published | not published | — |
| 6516 | Transmitter, TQ 2.4GHz, 2-channel (transmitter only) | electronics | ['2.4GHz', '2-channel'] | not published | — |
| 6518 | Receiver, micro, TQi 2.4GHz with telemetry (5-channel) | electronics | ['2.4GHz', '5-channel'] | not published | — |
| 6519 | Receiver, micro, TQ 2.4GHz (3-channel) | electronics | ['2.4GHz', '3-channel'] | not published | — |
| 6520 | Sensor, RPM (long)/ 3x4mm BCS (2)/ 3x4 GS (1) | electronics | ['3x4mm BCS', '3x4 GS'] | not published | — |
| 6521 | Sensor, temperature and voltage (long) | electronics | not published | not published | — |
| 6525 | Communication link, telemetry expander | electronics | not published | not published | — |
| 6526 | Sensor, auto-detectable, temperature | electronics | not published | not published | — |
| 6527 | Sensor, auto-detectable, voltage | electronics | not published | not published | — |
| 6528 | Transmitter, TQi Traxxas Link™ enabled, 2.4GHz high output, 2-channel (transmitter only) | electronics | ['2.4GHz', '2-channel'] | not published | — |
| 6529 | Transmitter, TQi Traxxas Link™ enabled, 2.4GHz high output, 3-channel (transmitter only) | electronics | ['2.4GHz', '3-channel'] | not published | — |
| 6530 | Transmitter, TQi Traxxas Link™ enabled, 2.4GHz high output, 4-channel (transmitter only) | electronics | ['2.4GHz', '4-channel'] | not published | — |
| 6535 | Mount, temperature sensor (electric motors)/ wire tie/ thermal pad | electronics | not published | not published | — |
| 6537 | Wire retainers, gear cover/ 3x4mm BCS (2) | electronics | ['3x4mm BCS'] | not published | — |
| 6538 | Telemetry trigger magnet holders, spur gear/ magnet, 5x2mm (1)/ 3x8mm CCS (3)/ 3x10mm CCS (3) | electronics | ['5x2mm', '3x8mm CCS', '3x10mm CCS'] | not published | — |
| 6540 | Telemetry trigger magnet, 5X2mm (1) | electronics | ['5X2mm'] | not published | — |
| 6541 | Connector, power tap (with cable) (long)/ wire tie | electronics | not published | not published | — |
| 6548 | Battery door, transmitter (replacement for #6516, 6517, 6528, 6529, 6530 transmitters) | electronics | not published | not published | — |
| 6550X | Telemetry expander 2.0, TQi radio system (for use only with #6551X GPS module) | electronics | not published | not published | — |
| 6551X | Telemetry GPS module 2.0, TQi radio system (for use only with #6550X telemetry expander) | electronics | not published | not published | — |
| 6552 | Seal kit, expander box (includes o-ring, seals, and silicone grease) | electronics | not published | not published | — |
| 6553X | Telemetry expander 2.0 and GPS module 2.0, TQi radio system | electronics | not published | not published | — |
| 6554 | Mount, telemetry expander (fits Bandit, Rustler®, Slash 2WD) | electronics | not published | not published | traxxas-rustler-2wd |
| 1726 | Antenna, tube (1)/ vinyl antenna cap (1)/ wire retainer (1) | body | not published | not published | — |
| 1815 | Body washers (8) | body | not published | not published | — |
| 1914R | Body mount, front & rear (black)/ body posts, 52mm (2), 38mm (2), 25mm (2), 6.5mm (2)/ body post extensions (4)/ hardware | body | ['52mm', '38mm', '25mm', '6.5mm'] | not published | — |
| 1926 | Antenna caps, vinyl (2)/ antenna spool | body | not published | not published | — |
| 3934 | Body clips, heavy duty (12) | body | not published | not published | — |
| 3935 | Body clip (mounting clip), angled, 90-degrees (10) | body | not published | not published | — |
| 3935A | Body clip (mounting clip), angled, 90-degrees (black) (10) | body | not published | not published | — |
| 5813 | Decal Sheet, Slash | body | not published | not published | — |
| 5846 | Paint masks, body | body | not published | not published | — |
| 6716 | Body washers, foam, 2mm (2)/ 3mm (2)/ 4mm (4) | body | ['2mm', '3mm', '4mm'] | not published | — |
| 6811 | Body, Slash 4X4 (clear, requires painting)/ window masks/ decal sheet | body | not published | not published | traxxas-slash-4x4-vxl |
| 6811R | Body, Slash 4X4, heavy duty (clear, untrimmed, requires painting)/ window masks/ decal sheet | body | not published | not published | traxxas-slash-4x4-vxl |
| 6811X | Body, Slash 4X4, ProGraphix (Graphics are printed, requires paint & final color application)/ decal sheet | body | not published | not published | traxxas-slash-4x4-vxl |
| 6849 | Body, Slash 4X4/Slash, Fox Edition (painted, decals applied) | body | not published | not published | traxxas-slash-4x4-vxl |
| 1589 | Double-sided adhesive tape (25mm x 25mm) (2) | hardware | ['25mm'] | not published | — |
| 1633 | E-clips/ C-rings | hardware | not published | not published | — |
| 1675 | Bushings, self-lubricating (5x11x4mm) (14) | hardware | ['5x11x4mm'] | not published | — |
| 1747 | Nuts, 4mm nylon locking (10) | hardware | ['4mm'] | not published | — |
| 1747A | Nuts, aluminum, flanged, serrated (4mm) (red-anodized) (4) | hardware | ['4mm'] | not published | — |
| 1747G | Nuts, aluminum, flanged, serrated (4mm) (green-anodized) (4) | hardware | ['4mm'] | not published | — |
| 1747P | Nuts, aluminum, flanged, serrated (4mm) (pink-anodized) (4) | hardware | ['4mm'] | not published | — |
| 1747R | Nuts, aluminum, flanged, serrated (4mm) (blue-anodized) (4) | hardware | ['4mm'] | not published | — |
| 1985 | PTFE-coated washers, 5x8x0.5mm (20) (use with ball bearings) | hardware | ['5x8x0.5mm'] | not published | — |
| 2542 | Screws, 4x12mm countersunk machine (hex drive) (6) | hardware | ['4x12mm countersunk machine (hex drive)'] | not published | — |
| 2545 | Bellcrank bushings (plastic) (5x8x2.5mm) (4) | hardware | ['5x8x2.5mm'] | not published | — |
| 2546 | Screws, 4x15mm countersunk machine (hex drive) (6) | hardware | ['4x15mm countersunk machine (hex drive)'] | not published | — |
| 2552 | Screws, 3x12mm countersunk machine (6) (hex drive) | hardware | ['3x12mm countersunk machine'] | not published | — |
| 2575 | Screws, 3x6mm button-head machine (hex drive) (6) | hardware | ['3x6mm button-head machine (hex drive)'] | not published | — |
| 2576 | Screws, 3x8mm button-head machine (hex drive) (6) | hardware | ['3x8mm button-head machine (hex drive)'] | not published | — |
| 2577 | Screws, 3x10mm button-head machine (hex drive) (6) | hardware | ['3x10mm button-head machine (hex drive)'] | not published | — |
| 2578 | Screws, 3x12mm button-head machine (hex drive) (6) | hardware | ['3x12mm button-head machine (hex drive)'] | not published | — |
| 2579 | Screws, 3x15mm button-head machine (hex drive) (6) | hardware | ['3x15mm button-head machine (hex drive)'] | not published | — |
| 2580 | Screws, 3x20mm button-head machine (hex drive) (6) | hardware | ['3x20mm button-head machine (hex drive)'] | not published | — |
| 2582 | Screws, 3x30mm button-head machine (hex drive) (6) | hardware | ['3x30mm button-head machine (hex drive)'] | not published | — |
| 2583 | Screws, 3x18mm button-head machine (hex drive) (6) | hardware | ['3x18mm button-head machine (hex drive)'] | not published | — |
| 2586 | Screws, 3x15mm cap-head machine (hex drive) (6) | hardware | ['3x15mm cap-head machine (hex drive)'] | not published | — |
| 2591 | Screws, 3x23mm button-head machine (hex drive) (6) | hardware | ['3x23mm button-head machine (hex drive)'] | not published | — |
| 2592 | Screws, 3x40mm button-head machine (hex drive) (6) | hardware | ['3x40mm button-head machine (hex drive)'] | not published | — |
| 2728 | Ball bearings (5x8x2.5mm) (2) | hardware | ['5x8x2.5mm'] | not published | — |
| 2742X | Rod ends, short (6)/ hollow balls (6) | hardware | not published | not published | — |
| 2743 | Set (grub) screws, 3mm hardened (12) | hardware | ['3mm'] | not published | — |
| 2745 | Nuts, 3mm nylon locking (12) | hardware | ['3mm'] | not published | — |
| 2746 | Washers, 3x6mm metal (12) | hardware | ['3x6mm'] | not published | — |
| 2754 | Stub axle pins (4) | hardware | not published | not published | — |
| 3215 | Screws, 2.5x6mm cap-head machine (hex drive) (6) | hardware | ['2.5x6mm cap-head machine (hex drive)'] | not published | — |
| 3642X | Shoulder screws, Ultra Shocks (3x12 hex drive) (6) | hardware | not published | not published | — |
| 3646 | Screws, 3x15mm flat-head machine (hex drive) (6) | hardware | ['3x15mm flat-head machine (hex drive)'] | not published | — |
| 3647 | Nuts, 4mm flanged nylon locking (steel, serrated) (8) | hardware | ['4mm'] | not published | — |
| 3742 | Shoulder screws, steering bellcranks (3x30mm cap-head machine) (2)/ draglink shoulder screws (chrome) (2) | hardware | ['3x30mm cap-head machine'] | not published | — |
| 3931 | Screws, 3x8mm flat-head machine (hex drive) (6) | hardware | ['3x8mm flat-head machine (hex drive)'] | not published | — |
| 3932 | Screws, 3x6mm flat-head machine (hex drive) (6) | hardware | ['3x6mm flat-head machine (hex drive)'] | not published | — |
| 3937 | Screws, 4x12mm button-head machine (hex drive) (6) | hardware | ['4x12mm button-head machine (hex drive)'] | not published | — |
| 3965 | Screws, 2.5x8mm cap-head machine (6) | hardware | ['2.5x8mm cap-head machine'] | not published | — |
| 4607 | Ball bearings (5x11x4mm) (8) | hardware | ['5x11x4mm'] | not published | — |
| 4859 | Screws, 3x10mm flat-head machine (hex drive) (4) | hardware | ['3x10mm flat-head machine (hex drive)'] | not published | — |
| 5114 | Ball bearings, blue rubber sealed (5x8x2.5mm) (2) | hardware | ['5x8x2.5mm'] | not published | — |
| 5116 | Ball bearings, blue rubber sealed (5x11x4mm) (2) | hardware | ['5x11x4mm'] | not published | — |
| 5347 | Rod ends, Revo® (large) with hollow balls (12) | hardware | not published | not published | — |
| 5525 | Rod ends (12)/ hollow balls (12) | hardware | not published | not published | — |
| 5529 | Shim set, 3x7x1mm (2), 3x6x0.5mm (4), 3x7x2mm (2)/ hollow balls, captured (4) | hardware | ['3x7x1mm', '3x6x0.5mm', '3x7x2mm'] | not published | — |
Where the files are
Other publishers' files are linked, not hosted. "verify" = check the license at the link before commercial use.
| Traxxas (sheet hosted by JEGS) | Slash 2WD Unassembled Kit (Model 58014-4) parts list, REV. 201103 1248, p. 1 | web | Publisher's page; dimensions are facts |
Free files
★ Free files 42 parts. Generated by Xem Studio from the standard; threads are plain cylinders at major diameter. CC BY 4.0. index.json
Use this part in your AI. Your AI gets the exact sizes and files straight from Xem and can design a mount, case or adapter around it. Direct downloads here are limited to one file every 10 minutes; through your AI they are unlimited.
Connect Xem to your AI (free, no account, about a minute)
https://xemstudio.com/mcp- Claude: Add to Claude
- ChatGPT (Plus or higher): open Connectors → Advanced → turn on Developer mode → Create → paste the address, no authentication → Create.
- Cursor: install with one click. VS Code: install with one click.
| traxxas-4607-ball-bearings-5x11x4mm-envelope | Bearing envelope 5 × 11 × 4 mm (bore × OD × width) | STEP · STL |
| traxxas-2728-ball-bearings-5x8x2-5mm-envelope | Bearing envelope 5 × 8 × 2.5 mm (bore × OD × width) | STEP · STL |
| traxxas-5116-ball-bearings-blue-rubber-sealed-5x11x4mm-envelope | Bearing envelope 5 × 11 × 4 mm (bore × OD × width) | STEP · STL |
| traxxas-5114-ball-bearings-blue-rubber-sealed-5x8x2-5mm-envelope | Bearing envelope 5 × 8 × 2.5 mm (bore × OD × width) | STEP · STL |
| traxxas-1985-ptfe-coated-washers-5x8x0-5mm-use-with-ball-bearings-envelope | Bearing envelope 5 × 8 × 0.5 mm (bore × OD × width) | STEP · STL |
| traxxas-2586-screws-3x15mm-cap-head-machine-hex-drive-envelope | M3 × 15 mm, shank as a plain Ø3 cylinder, ISO 4762 cap head Ø5.5 × 3 mm | STEP · STL |
| traxxas-3215-screws-2-5x6mm-cap-head-machine-hex-drive-envelope | M2.5 × 6 mm, shank as a plain Ø2.5 cylinder, ISO 4762 cap head Ø4.5 × 2.5 mm | STEP · STL |
| traxxas-3965-screws-2-5x8mm-cap-head-machine-envelope | M2.5 × 8 mm, shank as a plain Ø2.5 cylinder, ISO 4762 cap head Ø4.5 × 2.5 mm | STEP · STL |
| traxxas-2577-screws-3x10mm-button-head-machine-hex-drive-envelope | M3 × 10 mm, shank as a plain Ø3 cylinder, ISO 7380 button head Ø5.7 × 1.65 mm | STEP · STL |
| traxxas-4859-screws-3x10mm-flat-head-machine-hex-drive-envelope | M3 × 10 mm, shank as a plain Ø3 cylinder, ISO 10642 flat (countersunk) head Ø6 × 1.7 mm | STEP · STL |
| traxxas-2578-screws-3x12mm-button-head-machine-hex-drive-envelope | M3 × 12 mm, shank as a plain Ø3 cylinder, ISO 7380 button head Ø5.7 × 1.65 mm | STEP · STL |
| traxxas-2552-screws-3x12mm-countersunk-machine-hex-drive-envelope | M3 × 12 mm, shank as a plain Ø3 cylinder, ISO 10642 flat (countersunk) head Ø6 × 1.7 mm | STEP · STL |
| traxxas-2579-screws-3x15mm-button-head-machine-hex-drive-envelope | M3 × 15 mm, shank as a plain Ø3 cylinder, ISO 7380 button head Ø5.7 × 1.65 mm | STEP · STL |
| traxxas-3646-screws-3x15mm-flat-head-machine-hex-drive-envelope | M3 × 15 mm, shank as a plain Ø3 cylinder, ISO 10642 flat (countersunk) head Ø6 × 1.7 mm | STEP · STL |
| traxxas-2583-screws-3x18mm-button-head-machine-hex-drive-envelope | M3 × 18 mm, shank as a plain Ø3 cylinder, ISO 7380 button head Ø5.7 × 1.65 mm | STEP · STL |
| traxxas-2580-screws-3x20mm-button-head-machine-hex-drive-envelope | M3 × 20 mm, shank as a plain Ø3 cylinder, ISO 7380 button head Ø5.7 × 1.65 mm | STEP · STL |
| traxxas-2591-screws-3x23mm-button-head-machine-hex-drive-envelope | M3 × 23 mm, shank as a plain Ø3 cylinder, ISO 7380 button head Ø5.7 × 1.65 mm | STEP · STL |
| traxxas-2582-screws-3x30mm-button-head-machine-hex-drive-envelope | M3 × 30 mm, shank as a plain Ø3 cylinder, ISO 7380 button head Ø5.7 × 1.65 mm | STEP · STL |
| traxxas-2592-screws-3x40mm-button-head-machine-hex-drive-envelope | M3 × 40 mm, shank as a plain Ø3 cylinder, ISO 7380 button head Ø5.7 × 1.65 mm | STEP · STL |
| traxxas-2575-screws-3x6mm-button-head-machine-hex-drive-envelope | M3 × 6 mm, shank as a plain Ø3 cylinder, ISO 7380 button head Ø5.7 × 1.65 mm | STEP · STL |
| traxxas-3932-screws-3x6mm-flat-head-machine-hex-drive-envelope | M3 × 6 mm, shank as a plain Ø3 cylinder, ISO 10642 flat (countersunk) head Ø6 × 1.7 mm | STEP · STL |
| traxxas-2576-screws-3x8mm-button-head-machine-hex-drive-envelope | M3 × 8 mm, shank as a plain Ø3 cylinder, ISO 7380 button head Ø5.7 × 1.65 mm | STEP · STL |
| traxxas-3931-screws-3x8mm-flat-head-machine-hex-drive-envelope | M3 × 8 mm, shank as a plain Ø3 cylinder, ISO 10642 flat (countersunk) head Ø6 × 1.7 mm | STEP · STL |
| traxxas-3937-screws-4x12mm-button-head-machine-hex-drive-envelope | M4 × 12 mm, shank as a plain Ø4 cylinder, ISO 7380 button head Ø7.6 × 2.2 mm | STEP · STL |
| traxxas-2542-screws-4x12mm-countersunk-machine-hex-drive-envelope | M4 × 12 mm, shank as a plain Ø4 cylinder, ISO 10642 flat (countersunk) head Ø8 × 2.3 mm | STEP · STL |
| traxxas-2546-screws-4x15mm-countersunk-machine-hex-drive-envelope | M4 × 15 mm, shank as a plain Ø4 cylinder, ISO 10642 flat (countersunk) head Ø8 × 2.3 mm | STEP · STL |
| traxxas-3742-shoulder-screws-steering-bellcranks-3x30mm-cap-head-machine-draglin-envelope | M3 × 30 mm, shank as a plain Ø3 cylinder, ISO 4762 cap head Ø5.5 × 3 mm | STEP · STL |
| traxxas-3736-steering-blocks-left-right-requires-5x11x4mm-bearings-envelope | Bearing envelope 5 × 11 × 4 mm (bore × OD × width) | STEP · STL |
| traxxas-3752-stub-axle-carriers-requires-5x11x4mm-bearings-envelope | Bearing envelope 5 × 11 × 4 mm (bore × OD × width) | STEP · STL |
| traxxas-4628r-differential-output-yokes-black-3x5mm-countersunk-screws-screw-pin-envelope | M3 × 5 mm, shank as a plain Ø3 cylinder, ISO 10642 flat (countersunk) head Ø6 × 1.7 mm | STEP · STL |
| traxxas-2554-screws-3x6mm-cap-head-machine-hex-drive-envelope | M3 × 6 mm, shank as a plain Ø3 cylinder, ISO 4762 cap head Ø5.5 × 3 mm | STEP · STL |
| traxxas-2416-gear-16-t-pinion-48-pitch-set-screw-profile | 16-tooth 48-pitch gear, 20° involute, module 0.5292 mm, Ø9.52 OD — 1 mm reference (face width not printed) | STEP · STL |
| traxxas-1918-gear-18-t-pinion-48-pitch-set-screw-profile | 18-tooth 48-pitch gear, 20° involute, module 0.5292 mm, Ø10.58 OD — 1 mm reference (face width not printed) | STEP · STL |
| traxxas-2419-gear-19-t-pinion-48-pitch-set-screw-profile | 19-tooth 48-pitch gear, 20° involute, module 0.5292 mm, Ø11.11 OD — 1 mm reference (face width not printed) | STEP · STL |
| traxxas-2423-gear-23-t-pinion-48-pitch-set-screw-profile | 23-tooth 48-pitch gear, 20° involute, module 0.5292 mm, Ø13.23 OD — 1 mm reference (face width not printed) | STEP · STL |
| traxxas-2426-gear-26-t-pinion-48-pitch-set-screw-profile | 26-tooth 48-pitch gear, 20° involute, module 0.5292 mm, Ø14.82 OD — 1 mm reference (face width not printed) | STEP · STL |
| traxxas-2431-gear-31-t-pinion-48-pitch-set-screw-profile | 31-tooth 48-pitch gear, 20° involute, module 0.5292 mm, Ø17.46 OD — 1 mm reference (face width not printed) | STEP · STL |
| traxxas-4725-gear-pinion-25-tooth-48-pitch-set-screw-profile | 25-tooth 48-pitch gear, 20° involute, module 0.5292 mm, Ø14.29 OD — 1 mm reference (face width not printed) | STEP · STL |
| traxxas-4728-gear-pinion-28-tooth-48-pitch-set-screw-profile | 28-tooth 48-pitch gear, 20° involute, module 0.5292 mm, Ø15.88 OD — 1 mm reference (face width not printed) | STEP · STL |
| traxxas-4683-spur-gear-83-tooth-48-pitch-for-models-with-torque-control-slipper-profile | 83-tooth 48-pitch gear, 20° involute, module 0.5292 mm, Ø44.98 OD — 1 mm reference (face width not printed) | STEP · STL |
| traxxas-4686-spur-gear-86-tooth-48-pitch-for-models-with-torque-control-slipper-profile | 86-tooth 48-pitch gear, 20° involute, module 0.5292 mm, Ø46.57 OD — 1 mm reference (face width not printed) | STEP · STL |
| traxxas-4690-spur-gear-90-tooth-48-pitch-for-models-with-torque-control-slipper-profile | 90-tooth 48-pitch gear, 20° involute, module 0.5292 mm, Ø48.68 OD — 1 mm reference (face width not printed) | STEP · STL |
https://xemstudio.com/mcp to Claude, ChatGPT, Cursor or any MCP client (free, no account, one minute) and it can look up exact sizes, mating fits and free STEP/STL from every chat.Plain text: sheet.txt · JSON: /api/geometry?object=traxxas-slash-2wd-parts-list

Fits with
Questions
Where do the Traxxas Slash 2WD kit (58014-4) part numbers come from?
The maker's manual or official spare-parts listing; every row cites its source.
How many parts are listed for the Traxxas Slash 2WD kit (58014-4)?
373, of which 159 have sizes printed by the maker.
