8 in floppy disk (200 mm)

What are the exact dimensions of an 8 inch floppy disk? · Modern device · basis: ECMA-69, 200 mm flexible disk cartridge, double-density two-sided

Also called: 8 inch floppy disk dimensions, 8 inch floppy size mm, 8" diskette size, disquete 8 pulgadas medidas, disquete 8 polegadas, Diskette 8 Zoll Maße

Exact dimensions. True size, with no tolerance added.

length
203.2 mm
width
203.2 mm
height
2.1 mm

Notes

  • An 8 inch floppy disk jacket is a 203.2 mm square (l1 = 203.2 ±0.4 mm, corners 90° ±30′) and between 1.2 and 2.1 mm thick overall (ECMA-69 §3.1). The central window is Ø58.40 ±0.15 mm, centred 101.6 mm from the reference edge — the middle of the jacket.
  • The file is the jacket at the published size: 203.2 × 203.2 mm, drawn 2.1 mm thick (the standard's maximum overall thickness), with the Ø58.4 mm central window at the jacket centre; no printing allowance. Index and head windows are listed above but not modelled.

8 in floppy disk size chart

dimensionvalue
jacket side (l1)203.2 mm ±0.4
corner angle90° ±30′
overall thickness (e2)over 1.2 mm, under 2.1 mm
gaugefalls freely through a 2.6 mm slot, 150 mm deep
central window (d1)Ø58.4 mm
central window centre (l2)101.6 mm ±0.3 from the reference edge
index window (d2)Ø7.7 mm ±0.1 at l3 85.09 / l4 135.95 mm ±0.25
jacket wall and liner (e1)0.45 mm ±0.15

Where the files are

Other publishers' files are linked, not hosted. "verify" = check the license at the link before commercial use.

Ecma InternationalECMA-69 (PDF)webPublisher's page; dimensions are facts

Free files

★ Free files 1 parts. Generated by Xem Studio from the standard; threads are plain cylinders at major diameter. CC BY 4.0. index.json

Use this part in your AI. Your AI gets the exact sizes and files straight from Xem and can design a mount, case or adapter around it. Direct downloads here are limited to one file every 10 minutes; through your AI they are unlimited.

Connect Xem to your AI (free, no account, about a minute)
https://xemstudio.com/mcp
  1. Claude: Add to Claude
  2. ChatGPT (Plus or higher): open Connectors → Advanced → turn on Developer mode → Create → paste the address, no authentication → Create.
  3. Cursor: install with one click. VS Code: install with one click.
Other apps and full steps
8-inch-floppy-disk-200-mm-jacketJacket 203.2 mm square × 2.1 mm, Ø58.4 central window (ECMA-69 nominal)STEP · STL
Let your AI pull this. Add https://xemstudio.com/mcp to Claude, ChatGPT, Cursor or any MCP client (free, no account, one minute) and it can look up exact sizes, mating fits and free STEP/STL from every chat.
Set it up →

Plain text: sheet.txt · JSON: /api/geometry?object=8-inch-floppy-disk-200-mm

8 in floppy disk (200 mm), isometric render of a generated part
Render of 8-inch-floppy-disk-200-mm-jacket from the free STEP; not to scale.

Fits with

Questions

How big is an 8 inch floppy disk?

The jacket is 203.2 mm square and under 2.1 mm thick, with a Ø58.4 mm centre window (ECMA-69).
