CD / DVD disc Ø120 × 1.2 mm with Ø15 hole (and mini CD Ø80)

What are the dimensions of a CD and its centre hole? · Standard part · basis: ECMA-130 / ISO 9660 physical disc: Ø120 × 1.2 mm, Ø15 mm centre hole; mini CD Ø80

Also called: cd dimensions, cd center hole size, dvd diameter mm, mini cd size, cd flywheel

Long Earth Society build part. Flywheels for the can engines; the hubs in the kit fit them to 3, 5 and 8 mm shafts. Long Earth Society

Exact dimensions. True size, with no tolerance added.

sizes
2 in table

Notes

  • CD, DVD and Blu-ray discs share one physical size: Ø120.0 × 1.2 mm with a Ø15.0 mm centre hole (held to +0.1), about 16 g.
  • The mini CD is Ø80 × 1.2 with the same Ø15 hole, about 7 g.
  • Both files are flat rings drawn at those nominal sizes; the hubs in the can-engine kit are drawn with a Ø15.0 spigot for the hole (see Mating features there).
  • On the can engine I use a CD as the flywheel: 16 g spread out to Ø120.

CD / DVD disc Ø120 × 1.2 mm with Ø15 hole size chart

discdia (mm)thickness (mm)hole (mm)mass (g)
CD / DVD / Blu-ray1201.21516
mini CD801.2157

Where the files are

Other publishers' files are linked, not hosted. "verify" = check the license at the link before commercial use.

WikipediaCompact discwebCC BY-SA 4.0 (text)
WikipediaHard disk drive platterwebCC BY-SA 4.0 (text)
Long Earth SocietyEngine builds (videos and write-ups)web, videoLES site

Free files

★ Free files 2 parts. Generated by Xem Studio from the standard; threads are plain cylinders at major diameter. CC BY 4.0. index.json

Use this part in your AI. Your AI gets the exact sizes and files straight from Xem and can design a mount, case or adapter around it. Direct downloads here are limited to one file every 10 minutes; through your AI they are unlimited.

Connect Xem to your AI (free, no account, about a minute)
https://xemstudio.com/mcp
  1. Claude: Add to Claude
  2. ChatGPT (Plus or higher): open Connectors → Advanced → turn on Developer mode → Create → paste the address, no authentication → Create.
  3. Cursor: install with one click. VS Code: install with one click.
Other apps and full steps
cd-dvd-120CD / DVD / Blu-ray: Ø120 × 1.2, Ø15 hole (Ø15.0 +0.1)STEP · STL
mini-cd-80Mini CD: Ø80 × 1.2, Ø15 holeSTEP · STL
Let your AI pull this. Add https://xemstudio.com/mcp to Claude, ChatGPT, Cursor or any MCP client (free, no account, one minute) and it can look up exact sizes, mating fits and free STEP/STL from every chat.
Set it up →

Plain text: sheet.txt · JSON: /api/geometry?object=cd-dvd-discs

CD / DVD disc Ø120 × 1.2 mm with Ø15 hole (and mini CD Ø80), isometric render of a generated part
Render of cd-dvd-120 from the free STEP; not to scale.

You might also need

Questions

What is the diameter of a CD centre hole?

15.0 mm (+0.1); the disc is Ø120 × 1.2 mm.

Is a DVD the same size as a CD?

Yes: Ø120 × 1.2 mm with a Ø15 hole; Blu-ray too.

How big is a mini CD?

Ø80 × 1.2 mm with the same Ø15 centre hole.
