Pulleys of the first system, 2 movable pulleys (4 : 1)
How does each movable pulley double the advantage? · Hardware · basis: Xem Studio design following Brown No. 19 (1868)
Also called: first system of pulleys, compound pulley, 4 to 1 pulley, runner tackle, sistema de poleas de primera clase (4:1), Potenzflaschenzug (4:1)
Exact dimensions. True size, with no tolerance added.
- sizes
- 4 in table
Notes
- Resize: multiply every length by one factor k and the motion stays identical: angles, ratios, timing and the formulas below do not change, because a mechanism's motion depends only on the ratios of its lengths. Here, scales with k: movable pulleys; step to the nearest standard size (and redraw the hole or pocket it fits): ropes.
- Resize: Mechanical advantage = number of rope segments holding the load, independent of size; sheave grooves follow the rope Ø you choose, not the scale factor.
- Resize: fit clearances stay in mm (a slide fit is the same gap at any size); keep every printed wall and pin at least two nozzle widths; mass grows with k³ but part strength only with k², so at k = 2 parts are about 8× heavier and 4× stronger: check pins and thin links when scaling up.
- Each movable pulley hangs in its own rope, one end fixed to the beam, the other tied to the next pulley up; the last rope goes to the hand. Every pulley halves the pull passed on, so P = W/2^n = W/4 with n = 2, and the hand moves 4 times as far as the weight.
- Pitch-Ø30 sheaves; ropes' standing ends in the beam at x = -15, 0; the hauling part comes up at x = 30. The runner blocks hang from the previous rope by a socket under their sheave.
- Brown's No. 19 (combinations following the rule that each movable pulley doubles the effect).
- Parts (each has its own page): tackle-beam-240-sockets, tackle-block-15-bottom-stem, tackle-block-15-bottom-socket, rope-sheave-3mm-pitch-30, ropes-3mm-first-system-pulleys-4-to-1, tackle-weight-d40x40-socket, dowel-pins-metric.
- Brown's movement No. 19 (1868) shows it; this model is a Xem Studio design following his figure, every part at true size.
Pulleys of the first system, 2 movable pulleys size chart
| parameter | value |
|---|---|
| movable pulleys | 2 × pitch Ø30 |
| ropes | 2 |
| mechanical advantage | 4 |
| hand travel / weight travel | 4 |
Where the files are
Other publishers' files are linked, not hosted. "verify" = check the license at the link before commercial use.
| Henry T. Brown (1868, public domain) | Five Hundred and Seven Mechanical Movements — scan on archive.org | web | Publisher's page; dimensions are facts |
| 507movements.com | Brown's movement No. 19: figure, his text and an animation | web | Publisher's page; dimensions are facts |
Free files
★ Free files 1 parts. Xem Studio design: free to use, print and sell things from; not to be republished as files. Xem Studio Design License. index.json
Use this part in your AI. Your AI gets the exact sizes and files straight from Xem and can design a mount, case or adapter around it. Direct downloads here are limited to one file every 10 minutes; through your AI they are unlimited.
Connect Xem to your AI (free, no account, about a minute)
https://xemstudio.com/mcp- Claude: Add to Claude
- ChatGPT (Plus or higher): open Connectors → Advanced → turn on Developer mode → Create → paste the address, no authentication → Create.
- Cursor: install with one click. VS Code: install with one click.
| first-system-pulleys-4-to-1-mechanism-assembly | Assembled mechanism, all parts placed at one pose (STEP keeps each part separate) | STEP · STL |
https://xemstudio.com/mcp to Claude, ChatGPT, Cursor or any MCP client (free, no account, one minute) and it can look up exact sizes, mating fits and free STEP/STL from every chat.Plain text: sheet.txt · JSON: /api/geometry?object=first-system-pulleys-4-to-1-mechanism

Fits with







Questions
How does each movable pulley double the advantage?
Each movable pulley hangs in its own rope, one end fixed to the beam, the other tied to the next pulley up; the last rope goes to the hand. Every pulley halves the pull passed on, so P = W/2^n = W/4 with n = 2, and the hand moves 4 times as far as the weight.
