Gemfan 1608 40 mm 3-blade propeller (1.5 mm)

What are the dimensions of the Gemfan 1608 40 mm 3-blade propeller (1.5 mm)? · Modern device · basis: Secondary source: GetFPV (copy of the maker's figures; the maker publishes none directly)

Also called: Gemfan 1608 dimensions, Gemfan 1608 hub thickness, Gemfan 1608 bore, Gemfan 1608 weight, Gemfan 1608 shaft size, Gemfan 1608 specs, dimensiones hélice Gemfan 1608, Gemfan 1608 Propeller Abmessungen, 40mm whoop prop, Meteor75 Pro props

Exact dimensions. True size, with no tolerance added.

length
40 mm
width
40 mm
height
5 mm

Notes

  • Whoop prop for 1102-class motors on 1.5 mm shafts.
  • No CAD file: the maker publishes only overall sizes, and a plain box or cylinder is not useful design geometry. The table is the published data; parts with real geometry have their own pages.
  • Secondary source: the numbers come from a retailer or magazine copy of the maker's specification.

Gemfan 1608 40 mm 3-blade propeller size chart

dimensionvalue
Diameter40 mm (1.6 in)
Pitch0.8 in
Hub thickness5 mm
Bore / mount1.5 mm hub ID
Weight0.42 g
Blades3

Where the files are

Other publishers' files are linked, not hosted. "verify" = check the license at the link before commercial use.

GetFPVGemfan 40mm 1608 3-Blade PC (1.5mm)webPublisher's page; dimensions are facts

Xem scan

File coming

No downloadable true-size file yet: the published figures do not fix the whole shape, and Xem never guesses a number. A measured scan is planned; request it and it moves up.

Votes decide what gets scanned first.

+1 for a scan of Gemfan 1608 40 mm 3-blade propeller (1.5 mm)

Your vote moves it up the list. Email is optional: only if you want one message when the file is ready.

Let your AI pull this. Add https://xemstudio.com/mcp to Claude, ChatGPT, Cursor or any MCP client (free, no account, one minute) and it can look up exact sizes, mating fits and free STEP/STL from every chat.
Set it up →

Plain text: sheet.txt · JSON: /api/geometry?object=gemfan-1608-40mm-3-blade

Gemfan 1608 40 mm 3-blade propeller (1.5 mm), isometric render of a generated part
Schematic, not to scale.

Fits with

Questions

What shaft does the Gemfan 1608 40 mm 3-blade propeller (1.5 mm) fit?

Bore/mount: 1.5 mm hub ID; hub thickness 5 mm.
