NEMA 17 stepper motor

What are the NEMA 17 mounting dimensions? · Standard part · basis: NEMA ICS 16 frame standard; common vendor values

Also called: nema17, nema 17, 17hs, nema stepper motor size chart, nema frame sizes, motor paso a paso tamaños nema, motor de passo tamanhos nema, nema 17 mounting hole spacing, motor paso a paso nema 17 medidas, motor de passo nema 17 dimensões

Long Earth Society build part. Doubles as a generator on the flywheel. Long Earth Society

Exact dimensions. Every file is drawn at true size with no tolerance added. The holes and pins that meet another part are listed below under Mating features, with the fit each joint needs; open those by your process's clearance before making the part. Mating features

width
42.3 mm
height
42.3 mm
holes
4 × Ø3.0 mm · 31 x 31 · M3

Notes

  • Face 42.3 × 42.3 mm; four M3 holes on a 31.0 × 31.0 mm pattern; Ø22 mm pilot boss, 2 mm tall; Ø5 mm shaft with a D-flat, typically 20–24 mm long.
  • Body length varies by torque (20–60 mm); the face and hole pattern don't.

Mating features

Drawn at the exact size. Open press, slide, run and socket features by your process's clearance (tolerances by process); leave designed gaps and clamp fits as drawn.

featureexactmates withfitfiles
pilot bossØ22 × 2mount pilot boreslidenema17-*
shaftØ5, D-flat 0.5 deepcoupler or pulley boreslidenema17-*
mount holesM3 tapped on 31M3 screws (Ø3.4 clearance in the mount)designednema17-*

Where the files are

Other publishers' files are linked, not hosted. "verify" = check the license at the link before commercial use.

WikipediaStepper motor (NEMA frame sizes)webCC BY-SA 4.0 (text)

Free files

★ Free files 3 parts. Generated by Xem Studio from the standard; threads are plain cylinders at major diameter. CC BY 4.0. index.json

Use this part in your AI. Your AI gets the exact sizes and files straight from Xem and can design a mount, case or adapter around it. Direct downloads here are limited to one file every 10 minutes; through your AI they are unlimited.

Connect Xem to your AI (free, no account, about a minute)
https://xemstudio.com/mcp
  1. Claude: Add to Claude
  2. ChatGPT (Plus or higher): open Connectors → Advanced → turn on Developer mode → Create → paste the address, no authentication → Create.
  3. Cursor: install with one click. VS Code: install with one click.
Other apps and full steps
nema17-34NEMA 17 envelope, 34 mm body, 31 mm M3 pattern, Ø5 D-shaftSTEP · STL
nema17-40NEMA 17 envelope, 40 mm body, 31 mm M3 pattern, Ø5 D-shaftSTEP · STL
nema17-48NEMA 17 envelope, 48 mm body, 31 mm M3 pattern, Ø5 D-shaftSTEP · STL
Let your AI pull this. Add https://xemstudio.com/mcp to Claude, ChatGPT, Cursor or any MCP client (free, no account, one minute) and it can look up exact sizes, mating fits and free STEP/STL from every chat.
Set it up →

Plain text: sheet.txt · JSON: /api/geometry?object=nema-17-stepper

NEMA 17 stepper motor, isometric render of a generated part
Render of nema17-40 from the free STEP; not to scale.

Fits with

Questions

What is the NEMA 17 mounting hole pattern?

Four M3 holes on a 31.0 × 31.0 mm square, 42.3 mm face, Ø22 mm pilot boss 2 mm tall.

What is the NEMA 17 shaft diameter?

5 mm with a D-flat, usually 20–24 mm long. Body length 20–60 mm depending on torque; the face never changes.
