608 ball bearing

What are the dimensions of a 608 bearing? · Standard part · basis: ISO 15 standard

Also called: 608, 608zz, 608-2rs, skate bearing

Long Earth Society build part. Flywheel shaft bearings. Long Earth Society

Exact dimensions. Every file is drawn at true size with no tolerance added. The holes and pins that meet another part are listed below under Mating features, with the fit each joint needs; open those by your process's clearance before making the part. Mating features

length
7 mm
width
22 mm
height
22 mm

Notes

  • Bore 8 mm, outer diameter 22 mm, width 7 mm. Shielded (ZZ) and sealed (2RS) are the same envelope.
  • Press fit in a Ø22.0 pocket, drawn at exactly Ø22.0; apply your press allowance to that pocket (see Mating features).

Mating features

Drawn at the exact size. Open press, slide, run and socket features by your process's clearance (tolerances by process); leave designed gaps and clamp fits as drawn.

featureexactmates withfitfiles
outer raceØ22 × 7housing bore Ø22 H7 (ISO 492/ABMA fit chart, stationary outer ring); pocket depth 7pressbearing-*
boreØ8 × 7shaft Ø8 h5 (light load) or js5 (normal load) for shafts up to 18 mm, rotating inner ringslidebearing-*
flangeØ25 × 1.5plate face the flange stops againstdesignedbearing-f*

Where the files are

Other publishers' files are linked, not hosted. "verify" = check the license at the link before commercial use.

WikipediaBall bearing (ISO designations)webCC BY-SA 4.0 (text)

Free files

★ Free files 2 parts. Generated by Xem Studio from the standard; threads are plain cylinders at major diameter. CC BY 4.0. index.json

Use this part in your AI. Your AI gets the exact sizes and files straight from Xem and can design a mount, case or adapter around it. Direct downloads here are limited to one file every 10 minutes; through your AI they are unlimited.

Connect Xem to your AI (free, no account, about a minute)
https://xemstudio.com/mcp
  1. Claude: Add to Claude
  2. ChatGPT (Plus or higher): open Connectors → Advanced → turn on Developer mode → Create → paste the address, no authentication → Create.
  3. Cursor: install with one click. VS Code: install with one click.
Other apps and full steps
bearing-608608: 8 × 22 × 7 mmSTEP · STL
bearing-f608F608 flanged: 8 × 22 × 7, flange Ø25 × 1.5STEP · STL
Let your AI pull this. Add https://xemstudio.com/mcp to Claude, ChatGPT, Cursor or any MCP client (free, no account, one minute) and it can look up exact sizes, mating fits and free STEP/STL from every chat.
Set it up →

Plain text: sheet.txt · JSON: /api/geometry?object=608-bearing

608 ball bearing, isometric render of a generated part
Render of bearing-f608 from the free STEP; not to scale.

You might also need

Questions

What are 608 bearing dimensions?

8 mm bore, 22 mm OD, 7 mm wide. ZZ (shielded) and 2RS (sealed) share the envelope. Pocket drawn at exactly Ø22.0.

What size is a skateboard bearing?

608: 8 × 22 × 7 mm, the same part used in fidget spinners and 3D printer idlers.
