Spur gears, module 1.5: 10 to 80 teeth (20° involute)
What is the pitch diameter of a module 1.5 spur gear? · Hardware · basis: ISO 53 basic rack: 20° pressure angle, addendum m, dedendum 1.25 m; pitch Ø = m × teeth, tip Ø = m × (teeth + 2), root Ø = m × (teeth − 2.5)
Also called: module 1.5 spur gear stl, m1.5 gear dimensions, spur gear calculator pitch diameter, involute gear step file, 3d printable gear
Exact dimensions. Every file is drawn at true size with no tolerance added. The holes and pins that meet another part are listed below under Mating features, with the fit each joint needs; open those by your process's clearance before making the part. Mating features
- sizes
- 26 in table
Notes
- Centre distance of two module 1.5 gears = m × (N1 + N2) / 2. Face width 12 mm, plain bore (add a hub, key or set screw to suit). Teeth below 17 are drawn without profile shift, so they undercut as real unshifted gears do.
Spur gears, module 1.5: 10 to 80 teeth size chart
| teeth | pitch dia (mm) | tip dia (mm) | root dia (mm) | face (mm) | bore (mm) |
|---|---|---|---|---|---|
| 10 | 15.0 | 18.0 | 11.25 | 12.0 | 4 |
| 12 | 18.0 | 21.0 | 14.25 | 12.0 | 5 |
| 14 | 21.0 | 24.0 | 17.25 | 12.0 | 6 |
| 15 | 22.5 | 25.5 | 18.75 | 12.0 | 7 |
| 16 | 24.0 | 27.0 | 20.25 | 12.0 | 7 |
| 18 | 27.0 | 30.0 | 23.25 | 12.0 | 8 |
| 20 | 30.0 | 33.0 | 26.25 | 12.0 | 9 |
| 22 | 33.0 | 36.0 | 29.25 | 12.0 | 10 |
| 24 | 36.0 | 39.0 | 32.25 | 12.0 | 11 |
| 25 | 37.5 | 40.5 | 33.75 | 12.0 | 12 |
| 28 | 42.0 | 45.0 | 38.25 | 12.0 | 13 |
| 30 | 45.0 | 48.0 | 41.25 | 12.0 | 14 |
| 32 | 48.0 | 51.0 | 44.25 | 12.0 | 15 |
| 35 | 52.5 | 55.5 | 48.75 | 12.0 | 17 |
| 36 | 54.0 | 57.0 | 50.25 | 12.0 | 18 |
| 40 | 60.0 | 63.0 | 56.25 | 12.0 | 20 |
| 42 | 63.0 | 66.0 | 59.25 | 12.0 | 21 |
| 45 | 67.5 | 70.5 | 63.75 | 12.0 | 22 |
| 48 | 72.0 | 75.0 | 68.25 | 12.0 | 24 |
| 50 | 75.0 | 78.0 | 71.25 | 12.0 | 25 |
| 56 | 84.0 | 87.0 | 80.25 | 12.0 | 25 |
| 60 | 90.0 | 93.0 | 86.25 | 12.0 | 25 |
| 64 | 96.0 | 99.0 | 92.25 | 12.0 | 25 |
| 70 | 105.0 | 108.0 | 101.25 | 12.0 | 25 |
| 72 | 108.0 | 111.0 | 104.25 | 12.0 | 25 |
| 80 | 120.0 | 123.0 | 116.25 | 12.0 | 25 |
Mating features
Drawn at the exact size. Open press, slide, run and socket features by your process's clearance (tolerances by process); leave designed gaps and clamp fits as drawn.
| feature | exact | mates with | fit | files |
|---|---|---|---|---|
| tooth form | 20° pressure angle, addendum 1.5, dedendum 1.875; pitch Ø = 1.5 × teeth (ISO 53 basic rack) | mating gear of the same module 1.5; centre distance = 1.5 × (N1 + N2) / 2 | designed | all |
| bore | Ø4 (10 teeth) to Ø25 (80 teeth), plain, per the table | shaft of the same Ø; add a hub, key or set screw to suit | slide | all |
| face width | 12 | shoulder or spacer on each face; keep the pair axially aligned | designed | all |
Where the files are
Other publishers' files are linked, not hosted. "verify" = check the license at the link before commercial use.
| ISO | ISO 53 standard basic rack (20° pressure angle, addendum 1 m, dedendum 1.25 m) and ISO 54 modules | standard | ISO; dimensions are facts verify |
Free files
★ Free files 26 parts. Generated by Xem Studio from the standard; threads are plain cylinders at major diameter. CC BY 4.0. index.json
Use this part in your AI. Your AI gets the exact sizes and files straight from Xem and can design a mount, case or adapter around it. Direct downloads here are limited to one file every 10 minutes; through your AI they are unlimited.
Connect Xem to your AI (free, no account, about a minute)
https://xemstudio.com/mcp- Claude: Add to Claude
- ChatGPT (Plus or higher): open Connectors → Advanced → turn on Developer mode → Create → paste the address, no authentication → Create.
- Cursor: install with one click. VS Code: install with one click.
| gear-m1-5-10t | module 1.5, 10 teeth: pitch Ø15, tip Ø18, root Ø11.25, face 12, bore Ø4 | STEP · STL |
| gear-m1-5-12t | module 1.5, 12 teeth: pitch Ø18, tip Ø21, root Ø14.25, face 12, bore Ø5 | STEP · STL |
| gear-m1-5-14t | module 1.5, 14 teeth: pitch Ø21, tip Ø24, root Ø17.25, face 12, bore Ø6 | STEP · STL |
| gear-m1-5-15t | module 1.5, 15 teeth: pitch Ø22.5, tip Ø25.5, root Ø18.75, face 12, bore Ø7 | STEP · STL |
| gear-m1-5-16t | module 1.5, 16 teeth: pitch Ø24, tip Ø27, root Ø20.25, face 12, bore Ø7 | STEP · STL |
| gear-m1-5-18t | module 1.5, 18 teeth: pitch Ø27, tip Ø30, root Ø23.25, face 12, bore Ø8 | STEP · STL |
| gear-m1-5-20t | module 1.5, 20 teeth: pitch Ø30, tip Ø33, root Ø26.25, face 12, bore Ø9 | STEP · STL |
| gear-m1-5-22t | module 1.5, 22 teeth: pitch Ø33, tip Ø36, root Ø29.25, face 12, bore Ø10 | STEP · STL |
| gear-m1-5-24t | module 1.5, 24 teeth: pitch Ø36, tip Ø39, root Ø32.25, face 12, bore Ø11 | STEP · STL |
| gear-m1-5-25t | module 1.5, 25 teeth: pitch Ø37.5, tip Ø40.5, root Ø33.75, face 12, bore Ø12 | STEP · STL |
| gear-m1-5-28t | module 1.5, 28 teeth: pitch Ø42, tip Ø45, root Ø38.25, face 12, bore Ø13 | STEP · STL |
| gear-m1-5-30t | module 1.5, 30 teeth: pitch Ø45, tip Ø48, root Ø41.25, face 12, bore Ø14 | STEP · STL |
| gear-m1-5-32t | module 1.5, 32 teeth: pitch Ø48, tip Ø51, root Ø44.25, face 12, bore Ø15 | STEP · STL |
| gear-m1-5-35t | module 1.5, 35 teeth: pitch Ø52.5, tip Ø55.5, root Ø48.75, face 12, bore Ø17 | STEP · STL |
| gear-m1-5-36t | module 1.5, 36 teeth: pitch Ø54, tip Ø57, root Ø50.25, face 12, bore Ø18 | STEP · STL |
| gear-m1-5-40t | module 1.5, 40 teeth: pitch Ø60, tip Ø63, root Ø56.25, face 12, bore Ø20 | STEP · STL |
| gear-m1-5-42t | module 1.5, 42 teeth: pitch Ø63, tip Ø66, root Ø59.25, face 12, bore Ø21 | STEP · STL |
| gear-m1-5-45t | module 1.5, 45 teeth: pitch Ø67.5, tip Ø70.5, root Ø63.75, face 12, bore Ø22 | STEP · STL |
| gear-m1-5-48t | module 1.5, 48 teeth: pitch Ø72, tip Ø75, root Ø68.25, face 12, bore Ø24 | STEP · STL |
| gear-m1-5-50t | module 1.5, 50 teeth: pitch Ø75, tip Ø78, root Ø71.25, face 12, bore Ø25 | STEP · STL |
| gear-m1-5-56t | module 1.5, 56 teeth: pitch Ø84, tip Ø87, root Ø80.25, face 12, bore Ø25 | STEP · STL |
| gear-m1-5-60t | module 1.5, 60 teeth: pitch Ø90, tip Ø93, root Ø86.25, face 12, bore Ø25 | STEP · STL |
| gear-m1-5-64t | module 1.5, 64 teeth: pitch Ø96, tip Ø99, root Ø92.25, face 12, bore Ø25 | STEP · STL |
| gear-m1-5-70t | module 1.5, 70 teeth: pitch Ø105, tip Ø108, root Ø101.25, face 12, bore Ø25 | STEP · STL |
| gear-m1-5-72t | module 1.5, 72 teeth: pitch Ø108, tip Ø111, root Ø104.25, face 12, bore Ø25 | STEP · STL |
| gear-m1-5-80t | module 1.5, 80 teeth: pitch Ø120, tip Ø123, root Ø116.25, face 12, bore Ø25 | STEP · STL |
https://xemstudio.com/mcp to Claude, ChatGPT, Cursor or any MCP client (free, no account, one minute) and it can look up exact sizes, mating fits and free STEP/STL from every chat.Plain text: sheet.txt · JSON: /api/geometry?object=spur-gears-module-1-5

Fits with









Questions
Pitch diameter of a module 1.5, 20-tooth gear?
30 mm; tip 33 mm.
Centre distance?
m × (N1 + N2) / 2: a 20 and a 40 tooth module 1.5 pair sit 45 mm apart.
