T-Motor AT2826 long-shaft fixed-wing motor (KV900)

What are the dimensions of the T-Motor AT2826 long-shaft fixed-wing motor? · Modern device · basis: Manufacturer specifications (T-Motor / LIGPOWER)

Also called: t-motor at2826 dimensions, at2826 long shaft, at2826 900kv, at2826 weight, at2826 f3a motor, tmotor at2826 shaft, at2826 medidas, at2826 abmessungen

Exact dimensions. True size, with no tolerance added.

length
35.2 mm
width
35.2 mm
height
69.5 mm

Notes

  • No CAD file: the maker publishes only overall sizes, and a plain box or cylinder is not useful design geometry. The table is the published data; parts with real geometry have their own pages.

T-Motor AT2826 long-shaft fixed-wing motor size chart

dimensionvalue
DimensionsΦ35.2 × 69.5 mm
Shaft5 mm in / 5 mm out
Weight incl. cable175 g
Kv900 (KV1100 also offered)
Max power (180 s)820 W (table)
Recommended propT13 × 6.5
Configuration12N14P

Where the files are

Other publishers' files are linked, not hosted. "verify" = check the license at the link before commercial use.

T-Motor / LIGPOWERAT2826 Long Shaft Fixed Wing MotorwebPublisher's page; dimensions are facts

Xem scan

File coming

No downloadable true-size file yet: the published figures do not fix the whole shape, and Xem never guesses a number. A measured scan is planned; request it and it moves up.

Votes decide what gets scanned first.

+1 for a scan of T-Motor AT2826 long-shaft fixed-wing motor (KV900)

Your vote moves it up the list. Email is optional: only if you want one message when the file is ready.

Let your AI pull this. Add https://xemstudio.com/mcp to Claude, ChatGPT, Cursor or any MCP client (free, no account, one minute) and it can look up exact sizes, mating fits and free STEP/STL from every chat.
Set it up →

Plain text: sheet.txt · JSON: /api/geometry?object=t-motor-at2826-long-shaft

T-Motor AT2826 long-shaft fixed-wing motor (KV900), isometric render of a generated part
Schematic, not to scale.

Fits with

Questions

How big is the AT2826?

Φ35.2 × 69.5 mm, 175 g, 5 mm shaft.
