Wedged through tenon joint
How does a wedged through tenon lock? · Hardware · basis: Xem Studio design — geometry computed in the generator from traditional proportions
Also called: wedged tenon, wedged through tenon, wedged mortise and tenon, fox wedge, espiga acuñada, verkeilter Zapfen
Exact dimensions. True size, with no tolerance added.
- length
- 80.0 mm
- width
- 80.0 mm
- height
- 20.0 mm
Notes
- Woodworking joint drawn for 3D printing: the parts lock together by shape, so a print can be joined without glue or screws. Drawn at true size with the parts line to line (zero gap) in their assembled position — add your printer's fit allowance to the mating faces (your AI or slicer can do this).
- The mortise is flared toward the far face; once the tenon is through, wedges driven beside it fill the flare and lock it like a dovetail.
Wedged through tenon joint size chart
| dimension | value |
|---|---|
| stock | 20 × 20 mm square |
| parts | stile, rail, wedge 1, wedge 2 |
| tenon | 15 × 6.67 mm, through |
| flare | 2 mm per side at the exit face (slope 1:10) |
| wedges | two, 2 mm thick at the head, 20 mm long |
| assembles | tenon in, then the wedges driven in from the exit face |
| holds | pull-out: the wedged tenon becomes a dovetail inside the flared mortise |
Where the files are
Other publishers' files are linked, not hosted. "verify" = check the license at the link before commercial use.
| Xem Studio | Joinery design (geometry computed in the generator from traditional proportions) | web | Xem Studio design |
Free files
★ Free files 5 parts. Xem Studio design: free to use, print and sell things from; not to be republished as files. Xem Studio Design License. index.json
Use this part in your AI. Your AI gets the exact sizes and files straight from Xem and can design a mount, case or adapter around it. Direct downloads here are limited to one file every 10 minutes; through your AI they are unlimited.
Connect Xem to your AI (free, no account, about a minute)
https://xemstudio.com/mcp- Claude: Add to Claude
- ChatGPT (Plus or higher): open Connectors → Advanced → turn on Developer mode → Create → paste the address, no authentication → Create.
- Cursor: install with one click. VS Code: install with one click.
| wedged-through-tenon-joint-stile | Mortise flared 2 mm per side toward the exit face | STEP · STL |
| wedged-through-tenon-joint-rail | Through tenon | STEP · STL |
| wedged-through-tenon-joint-wedge-1 | Wedge (fills one flare) | STEP · STL |
| wedged-through-tenon-joint-wedge-2 | Wedge (fills the other flare) | STEP · STL |
| wedged-through-tenon-joint-assembled | All parts in their assembled position (each part its own solid) | STEP · STL |
https://xemstudio.com/mcp to Claude, ChatGPT, Cursor or any MCP client (free, no account, one minute) and it can look up exact sizes, mating fits and free STEP/STL from every chat.Plain text: sheet.txt · JSON: /api/geometry?object=wedged-through-tenon-joint

Fits with
Questions
Can you 3D print a wedged tenon?
Yes: print the wedges flat; the zero-gap drawing is the locked state, so trim the wedges to taste.
