Eccentric sheaves Ø30 at 3, 5 and 8 mm offset
What is the stroke of an eccentric sheave? · Hardware · basis: Disc on a shaft offset e from its centre; stroke = 2e
Also called: eccentric sheave, eccentric cam 5mm shaft, eccentric drive, eccentric stroke
Used in Long Earth Society builds. Linear-to-rotational output converter
Exact dimensions. Every file is drawn at true size with no tolerance added. The holes and pins that meet another part are listed below under Mating features, with the fit each joint needs; open those by your process's clearance before making the part. Mating features
- sizes
- 3 in table
Notes
- A Ø30 × 8 disc with a Ø5 shaft hole offset 3, 5 or 8 mm from its centre: 6, 10 or 16 mm stroke.
- A radial Ø2.5 hole (M3 tap drill) at mid-thickness locks it to the shaft.
- It turns inside the Ø30 strap, which carries the load round its whole bore; it sits anywhere along a straight shaft without a crank throw.
Eccentric sheaves Ø30 at 3, 5 and 8 mm offset size chart
| file | offset e | stroke | disc | shaft |
|---|---|---|---|---|
| eccentric-d30-e3 | 3 | 6 | Ø30 × 8 | 5 |
| eccentric-d30-e5 | 5 | 10 | Ø30 × 8 | 5 |
| eccentric-d30-e8 | 8 | 16 | Ø30 × 8 | 5 |
Mating features
Drawn at the exact size. Open press, slide, run and socket features by your process's clearance (tolerances by process); leave designed gaps and clamp fits as drawn.
| feature | exact | mates with | fit | files |
|---|---|---|---|---|
| eccentric bore | Ø5 | Ø5 shaft | slide | eccentric-d30-e* |
| set-screw hole | Ø2.5 | M3 tap drill | designed | eccentric-d30-e* |
Where the files are
Other publishers' files are linked, not hosted. "verify" = check the license at the link before commercial use.
| Wikipedia | Eccentric (mechanism) | web | CC BY-SA 4.0 (text) |
| Long Earth Society | Engine and rig builds on extrusion frames | web, video | LES site |
Free files
★ Free files 3 parts. Xem Studio design: free to use, print and sell things from; not to be republished as files. Xem Studio Design License. index.json
Use this part in your AI. Your AI gets the exact sizes and files straight from Xem and can design a mount, case or adapter around it. Direct downloads here are limited to one file every 10 minutes; through your AI they are unlimited.
Connect Xem to your AI (free, no account, about a minute)
https://xemstudio.com/mcp- Claude: Add to Claude
- ChatGPT (Plus or higher): open Connectors → Advanced → turn on Developer mode → Create → paste the address, no authentication → Create.
- Cursor: install with one click. VS Code: install with one click.
| eccentric-d30-e3 | eccentric Ø30, 3 mm offset (6 mm stroke), Ø5 shaft, Ø2.5 set-screw hole | STEP · STL |
| eccentric-d30-e5 | eccentric Ø30, 5 mm offset (10 mm stroke), Ø5 shaft, Ø2.5 set-screw hole | STEP · STL |
| eccentric-d30-e8 | eccentric Ø30, 8 mm offset (16 mm stroke), Ø5 shaft, Ø2.5 set-screw hole | STEP · STL |
https://xemstudio.com/mcp to Claude, ChatGPT, Cursor or any MCP client (free, no account, one minute) and it can look up exact sizes, mating fits and free STEP/STL from every chat.Plain text: sheet.txt · JSON: /api/geometry?object=eccentric-sheaves

How it fits
Goes in or on
Connects to
Alternatives
You might also need
Questions
What is the stroke of an eccentric?
Twice the offset: the 5 mm eccentric gives 10 mm.
Why an eccentric instead of a crank?
It sits anywhere on a straight shaft with no throw, and the strap bears all the way round.
