Ratchet wheel stepped by a swinging pawl lever
How does a pawl lever step a ratchet wheel? · Hardware · basis: Xem Studio design following Brown No. 225 (1868)
Also called: ratchet feed, ratchet lever, intermittent ratchet, pawl and ratchet mechanism, trinquete con palanca de avance, Schaltwerk mit Klinkenhebel
Exact dimensions. True size, with no tolerance added.
- sizes
- 3 in table
Notes
- Resize: multiply every length by one factor k and the motion stays identical: angles, ratios, timing and the formulas below do not change, because a mechanism's motion depends only on the ratios of its lengths. Here, scales with k: pawl pivot radius; stays the same: wheel, step.
- Resize: fit clearances stay in mm (a slide fit is the same gap at any size); keep every printed wall and pin at least two nozzle widths; mass grows with k³ but part strength only with k², so at k = 2 parts are about 8× heavier and 4× stronger: check pins and thin links when scaling up.
- A lever swinging on the wheel's shaft carries a pawl: on the working stroke the pawl pushes a tooth's steep face and turns the wheel; on the return it rides back over the sloping backs. Rocking becomes step-by-step rotation, one or more teeth (15° each for 24 teeth) per stroke.
- Catalog 24-tooth Ø40 ratchet wheel with a feed pawl on a 30 mm arm; drawn at the start of a working stroke with the pawl's end face flat on the tooth's steep face (contact only).
- Brown's No. 225 (pawl on a vibrating arm turning a ratchet wheel intermittently). A light spring keeps the pawl down (not drawn).
- Parts (each has its own page): ratchet-wheels, ratchet-feed-pawl-24t-d40, ratchet-feed-arm-30, dowel-pins-metric.
- Brown's movement No. 225 (1868) shows it; this model is a Xem Studio design following his figure, every part at true size.
Ratchet wheel stepped by a swinging pawl lever size chart
| parameter | value |
|---|---|
| wheel | 24 T, Ø40 (catalog) |
| step | 15° per tooth |
| pawl pivot radius | 30 mm |
Where the files are
Other publishers' files are linked, not hosted. "verify" = check the license at the link before commercial use.
| Henry T. Brown (1868, public domain) | Five Hundred and Seven Mechanical Movements — scan on archive.org | web | Publisher's page; dimensions are facts |
| 507movements.com | Brown's movement No. 225: figure, his text and an animation | web | Publisher's page; dimensions are facts |
Free files
★ Free files 1 parts. Xem Studio design: free to use, print and sell things from; not to be republished as files. Xem Studio Design License. index.json
Use this part in your AI. Your AI gets the exact sizes and files straight from Xem and can design a mount, case or adapter around it. Direct downloads here are limited to one file every 10 minutes; through your AI they are unlimited.
Connect Xem to your AI (free, no account, about a minute)
https://xemstudio.com/mcp- Claude: Add to Claude
- ChatGPT (Plus or higher): open Connectors → Advanced → turn on Developer mode → Create → paste the address, no authentication → Create.
- Cursor: install with one click. VS Code: install with one click.
| ratchet-feed-lever-mechanism-assembly | Assembled mechanism, all parts placed at one pose (STEP keeps each part separate) | STEP · STL |
https://xemstudio.com/mcp to Claude, ChatGPT, Cursor or any MCP client (free, no account, one minute) and it can look up exact sizes, mating fits and free STEP/STL from every chat.Plain text: sheet.txt · JSON: /api/geometry?object=ratchet-feed-lever-mechanism

Fits with
Questions
How does a pawl lever step a ratchet wheel?
A lever swinging on the wheel's shaft carries a pawl: on the working stroke the pawl pushes a tooth's steep face and turns the wheel; on the return it rides back over the sloping backs. Rocking becomes step-by-step rotation, one or more teeth (15° each for 24 teeth) per stroke.
