Torsion spring wire Ø0.8, OD 8, 6 coils

What are the dimensions of a small torsion spring? · Hardware · basis: Close-wound helical torsion spring with two straight tangential legs; rate E d⁴ / (3667 D n) N·mm per degree

Also called: torsion spring design, torsion spring dimensions, small torsion spring step, pawl return spring

Long Earth Society build part. Pawl returns, diaphragm bias and belt tensioners on the LES rigs. Long Earth Society

Exact dimensions. Every file is drawn at true size with no tolerance added. The holes and pins that meet another part are listed below under Mating features, with the fit each joint needs; open those by your process's clearance before making the part. Mating features

sizes
5 in table

Notes

  • Six close-wound coils of 0.8 wire, OD 8, ID 6.4, with two straight legs reaching 10 mm from the coil axis. Envelope 14 × 8 × 5.7.
  • Torsion rate in N·mm per degree = E d⁴ / (3667 D n), E the wire's elastic modulus, D the mean Ø (7.2), n the coils.
  • The ID (6.4) goes over an arbor; the legs bear on the two parts it sets against each other, such as a pawl and its frame.

Torsion spring wire Ø0.8, OD 8, 6 coils size chart

featurevalue (mm)
wire Ø0.8
OD / ID8 / 6.4
coils6
leg reach from axis10
envelope14 × 8 × 5.7

Mating features

Drawn at the exact size. Open press, slide, run and socket features by your process's clearance (tolerances by process); leave designed gaps and clamp fits as drawn.

featureexactmates withfitfiles
spring ODOD (6–16)pocket of the same Øsocketall
spring IDOD − 2 × wireguide rod or arbor of the same Øsocketall

Where the files are

Other publishers' files are linked, not hosted. "verify" = check the license at the link before commercial use.

WikipediaSpring (device)webCC BY-SA 4.0 (text)
McMaster-CarrCompression springs (free STEP per part, for your own design use; no redistribution)STEP, PDFMcMaster-Carr site terms verify
Lee SpringSpring design formulaswebLee Spring site verify
Long Earth SocietyEngine and rig buildsweb, videoLES site

Free files

★ Free files 1 parts. Xem Studio design: free to use, print and sell things from; not to be republished as files. Xem Studio Design License. index.json

Use this part in your AI. Your AI gets the exact sizes and files straight from Xem and can design a mount, case or adapter around it. Direct downloads here are limited to one file every 10 minutes; through your AI they are unlimited.

Connect Xem to your AI (free, no account, about a minute)
https://xemstudio.com/mcp
  1. Claude: Add to Claude
  2. ChatGPT (Plus or higher): open Connectors → Advanced → turn on Developer mode → Create → paste the address, no authentication → Create.
  3. Cursor: install with one click. VS Code: install with one click.
Other apps and full steps
torsion-d0.8-od8-l10torsion spring envelope: wire Ø0.8, OD 8, ID 6.4, legs reaching 10 mm from the axis, 6 coilsSTEP · STL
Let your AI pull this. Add https://xemstudio.com/mcp to Claude, ChatGPT, Cursor or any MCP client (free, no account, one minute) and it can look up exact sizes, mating fits and free STEP/STL from every chat.
Set it up →

Plain text: sheet.txt · JSON: /api/geometry?object=torsion-spring

Torsion spring wire Ø0.8, OD 8, 6 coils, isometric render of a generated part
Render of torsion-d0.8-od8-l10 from the free STEP; not to scale.

You might also need

Questions

How do I calculate a torsion spring rate?

N·mm per degree = E·d⁴ / (3667·D·n), with D the mean coil Ø and n the coils.

What arbor fits the torsion spring?

The coil ID is 6.4.
