Slotted heat-exchange insert for a 2 in tri-clamp bore, 12 and 14 mm

What slotted insert works as a heat exchanger in a 2 inch tri-clamp tube? · Hardware · basis: Bore Ø47.5 (ASME BPE 2 in); slot width and depth from the thermal penetration depth in the network model (tools/gen_ta_power.py)

Also called: thermoacoustic heat exchanger insert, slotted heat exchanger tri clamp, internal fin insert 2 inch tube, thermoacoustic hot exchanger

Used in Long Earth Society builds. Custom high-temperature thermoacoustic engine (final design)

Exact dimensions. Every file is drawn at true size with no tolerance added. The holes and pins that meet another part are listed below under Mating features, with the fit each joint needs; open those by your process's clearance before making the part. Mating features

sizes
2 in table

Notes

  • A plug at the bore diameter with 60 radial slots 1 wide and 8 deep cut along its whole length. Gas passes through the slots; heat passes between the gas and the tube wall through the 60 fins left between them, each only 8 mm from the wall. The centre Ø31.5 is solid.
  • Slot hydraulic radius 0.44 mm; open area 27 % of the bore. In 20 bar helium at the generators' 25 Hz the thermal penetration depth is about 0.34 mm at 27 °C and 0.81 mm at 550 °C, so the gas in a slot is in good thermal contact.
  • 14 mm: the ambient exchangers, under the clamp-on water jacket (same length). 12 mm: the hot exchanger, under the fin sleeve and burner drum. The insert is pressed into the tube so the fins conduct into the wall (fit class press).
  • The exchanger works on the tube wall's temperature: the jacket, fin sleeve and drum outside are optional parts that set that temperature.

Slotted heat-exchange insert for a 2 in tri-clamp bore, 12 and 14 mm size chart

filelength (mm)slotsslot (mm)depth (mm)open area pct
hx-insert-2in-1414.0601.08.027.1
hx-insert-2in-1212.0601.08.027.1

Mating features

Drawn at the exact size. Open press, slide, run and socket features by your process's clearance (tolerances by process); leave designed gaps and clamp fits as drawn.

featureexactmates withfitfiles
outsideØ47.52 in spool bore: the fins conduct into the wallpressall
slots60 × 1.0 wide × 8 deep, full lengthgas passage (no contact)designedall
end facesflat Ø47.58.4 spacer, screen stack, buffer-tube linerdesignedall

Where the files are

Other publishers' files are linked, not hosted. "verify" = check the license at the link before commercial use.

G. W. Swift (Acoustical Society of America / LANL)Thermoacoustics: A Unifying Perspective for Some Engines and Refrigerators (Rott's equations, the energy equation, screen relations; the method behind DeltaEC)web, bookcited verify
Xem Studiotools/gen_ta_power.py: the network model and every dimension on this pagecodeCC BY 4.0
Long Earth SocietyEngine buildsweb, videoLES site

Free files

★ Free files 2 parts. Xem Studio design: free to use, print and sell things from; not to be republished as files. Xem Studio Design License. index.json

Use this part in your AI. Your AI gets the exact sizes and files straight from Xem and can design a mount, case or adapter around it. Direct downloads here are limited to one file every 10 minutes; through your AI they are unlimited.

Connect Xem to your AI (free, no account, about a minute)
https://xemstudio.com/mcp
  1. Claude: Add to Claude
  2. ChatGPT (Plus or higher): open Connectors → Advanced → turn on Developer mode → Create → paste the address, no authentication → Create.
  3. Cursor: install with one click. VS Code: install with one click.
Other apps and full steps
hx-insert-2in-14Ø47.5 × 14 plug with 60 radial slots 1 wide, 8 deep from the surface (to Ø31.5), solid centre: ambient exchangerSTEP · STL
hx-insert-2in-12Ø47.5 × 12 plug with 60 radial slots 1 wide, 8 deep from the surface (to Ø31.5), solid centre: hot exchangerSTEP · STL
Let your AI pull this. Add https://xemstudio.com/mcp to Claude, ChatGPT, Cursor or any MCP client (free, no account, one minute) and it can look up exact sizes, mating fits and free STEP/STL from every chat.
Set it up →

Plain text: sheet.txt · JSON: /api/geometry?object=tri-clamp-slotted-heat-exchange-insert

Slotted heat-exchange insert for a 2 in tri-clamp bore, 12 and 14 mm, isometric render of a generated part
Render of hx-insert-2in-12 from the free STEP; not to scale.

Fits with

Questions

Why slots instead of plates?

Every fin is joined to the wall it takes heat from, and a slotting cutter or wire makes them all the same.

Why a solid centre?

The centre is farthest from the wall; gas there would not exchange heat in one pass.
