Crosshead yokes with a Ø5 stub wrist pin: Ø6, Ø8 and hollow Ø10 rods

How do I join a con-rod to a piston rod outside the cylinder? · Hardware · basis: Design values; Ø5 dowel (ISO 8734) stub pin with a 625 in the con-rod's small end

Also called: crosshead yoke, stub pin rod end

Long Earth Society build part. The crossheads of my performance engines. Long Earth Society

Exact dimensions. Every file is drawn at true size with no tolerance added. The holes and pins that meet another part are listed below under Mating features, with the fit each joint needs; open those by your process's clearance before making the part. Mating features

sizes
3 in table

Notes

  • A block on the rod's end with a Ø5 dowel pressed 6 mm into its side: the con-rod's 625 runs on the pin beside the block and a Ø5 shaft collar holds it. The rod's axis stays clear, so in the beta the displacer rod passes straight up through the hollow rod's yoke (and its 6 × 10 × 10 bushing guides it there).

Crosshead yokes with a Ø5 stub wrist pin: Ø6, Ø8 and hollow Ø10 rods size chart

partsocketpin heightblock
yoke-rod6-m6M6 × 121514 × 14 × 24
yoke-rod8-m8M8 × 121614 × 14 × 26
yoke-tube10-m10x1M10 × 1 × 162214 × 24 × 30

Mating features

Drawn at the exact size. Open press, slide, run and socket features by your process's clearance (tolerances by process); leave designed gaps and clamp fits as drawn.

featureexactmates withfitfiles
rod socketsM6 (Ø5.0 × 12) / M8 (Ø6.8 × 12) / M10 × 1 (Ø9.0 × 16)rod endsdesignedall
stub-pin holeØ5 × 6Ø5 dowel wrist pinpressall
bushing seatØ10 × 10 at the top6 × 10 × 10 sleeve bushing (guides the displacer rod)pressyoke-tube10*

Where the files are

Other publishers' files are linked, not hosted. "verify" = check the license at the link before commercial use.

Long Earth SocietyEngine buildsweb, videoLES site

Free files

★ Free files 3 parts. Xem Studio design: free to use, print and sell things from; not to be republished as files. Xem Studio Design License. index.json

Use this part in your AI. Your AI gets the exact sizes and files straight from Xem and can design a mount, case or adapter around it. Direct downloads here are limited to one file every 10 minutes; through your AI they are unlimited.

Connect Xem to your AI (free, no account, about a minute)
https://xemstudio.com/mcp
  1. Claude: Add to Claude
  2. ChatGPT (Plus or higher): open Connectors → Advanced → turn on Developer mode → Create → paste the address, no authentication → Create.
  3. Cursor: install with one click. VS Code: install with one click.
Other apps and full steps
yoke-rod6-m6crosshead yoke 14 × 14 × 24 for the rod6 rod: tapped socket from the bottom, Ø5 stub-pin hole 6 deep in the −Y face at 15STEP · STL
yoke-rod8-m8crosshead yoke 14 × 14 × 26 for the rod8 rod: tapped socket from the bottom, Ø5 stub-pin hole 6 deep in the −Y face at 16STEP · STL
yoke-tube10-m10x1crosshead yoke 14 × 14 × 30 for the tube10 rod: tapped socket from the bottom, Ø5 stub-pin hole 6 deep in the −Y face at 22, Ø7 passage and Ø10 × 10 bushing seat at the topSTEP · STL
Let your AI pull this. Add https://xemstudio.com/mcp to Claude, ChatGPT, Cursor or any MCP client (free, no account, one minute) and it can look up exact sizes, mating fits and free STEP/STL from every chat.
Set it up →

Plain text: sheet.txt · JSON: /api/geometry?object=crosshead-yokes-stub-pin

Crosshead yokes with a Ø5 stub wrist pin: Ø6, Ø8 and hollow Ø10 rods, isometric render of a generated part
Render of yoke-rod8-m8 from the free STEP; not to scale.

Fits with

Questions

Why not a clevis?

A clevis pin crosses the rod's axis; the beta's coaxial rods need the axis clear.
