Hollow loose-fit pistons for tri-clamp spools: Ø33.6, Ø46 and Ø70.9
What hollow piston fits loosely in a 1.5, 2 or 3 inch tri-clamp spool? · Hardware · basis: 16 ga ASME BPE tube bores (1.5 in 34.8, 2 in 47.5, 3 in 72.9 mm) minus a designed radial gap of 0.6 / 0.75 / 1.0 mm (Senft, low-temperature-difference air engines)
Also called: tri clamp stirling displacer, displacer for 2 inch spool, stirling displacer stl, 46 mm displacer, tri clamp displacer dimensions
Used in Long Earth Society builds. Stirling engine displacer build (8" × 6"), aluminum flashing · Stirling engine displacer build (full walkthrough)
Exact dimensions. Every file is drawn at true size with no tolerance added. The holes and pins that meet another part are listed below under Mating features, with the fit each joint needs; open those by your process's clearance before making the part. Mating features
- sizes
- 9 in table
Notes
- The displacer is a closed cylinder that runs in the spool bore with a designed radial gap: 0.6 mm in the 1.5 in spool (Ø33.6 in Ø34.8), 0.75 mm in the 2 in (Ø46.0 in Ø47.5), 1.0 mm in the 3 in (Ø70.9 in Ø72.9). The gap is part of the design and is drawn as is.
- Lengths: 1.5 in 50 / 75 / 100, 2 in 60 / 90 / 120, 3 in 80 / 120 / 160 mm. Each length comes two ways: a hollow shell (1 mm wall, closed rounded end, 1.2 mm internal rings every 25 mm) with its end cap, and a solid body of the same diameter and length with a Ø3 centre hole and two 0.6 mm slots crossing on the axis through the full length, so the file is four quarter-segments around the centre hole.
- The shell's end cap has a spigot Ø(D − 2) × 3 that enters the shell, a Ø D × 1.5 flange, and a Ø16 × 6 boss with the Ø3 rod hole and a Ø2.5 radial hole for an M3 grub at 8 mm; the cap stands 10.5 mm overall. One cap file per spool size serves every length.
- The Ø3 rod is the displacer rod: it leaves through the displacer head or crank head on the cold end. Every hole that meets another part is in the Mating features table.
Hollow loose-fit pistons for tri-clamp spools: Ø33.6, Ø46 and Ø70.9 size chart
| spool (in) | bore (mm) | displacer od (mm) | length (mm) | radial gap (mm) |
|---|---|---|---|---|
| 1.5 | 34.8 | 33.6 | 50 | 0.6 |
| 1.5 | 34.8 | 33.6 | 75 | 0.6 |
| 1.5 | 34.8 | 33.6 | 100 | 0.6 |
| 2 | 47.5 | 46.0 | 60 | 0.75 |
| 2 | 47.5 | 46.0 | 90 | 0.75 |
| 2 | 47.5 | 46.0 | 120 | 0.75 |
| 3 | 72.9 | 70.9 | 80 | 1.0 |
| 3 | 72.9 | 70.9 | 120 | 1.0 |
| 3 | 72.9 | 70.9 | 160 | 1.0 |
Mating features
Drawn at the exact size. Open press, slide, run and socket features by your process's clearance (tolerances by process); leave designed gaps and clamp fits as drawn.
| feature | exact | mates with | fit | files |
|---|---|---|---|---|
| displacer OD in the spool bore | bore − 2 × 0.6 / 0.75 / 1.0 | tri-clamp-spool bore | designed | displacer-* |
| cap spigot in the shell | shell bore | displacer shell | slide | displacer-cap-* |
| cap rod hole | Ø3 | Ø3 displacer rod (M3 grub) | slide | displacer-cap-* |
| cap grub hole | Ø2.5 | M3 tap drill | designed | displacer-cap-* |
| displacer-body rod bore | Ø3 | Ø3 displacer rod | slide | displacer-body-* |
Where the files are
Other publishers' files are linked, not hosted. "verify" = check the license at the link before commercial use.
| Long Earth Society | Tri-clamp Stirling engine builds | web, video | LES site |
| James R. Senft | An Introduction to Low Temperature Differential Stirling Engines (displacer and gap design) | book | Moriya Press verify |
| Wikipedia | Stirling engine | web | CC BY-SA 4.0 (text) |
Free files
★ Free files 27 parts. Xem Studio design: free to use, print and sell things from; not to be republished as files. Xem Studio Design License. index.json
Use this part in your AI. Your AI gets the exact sizes and files straight from Xem and can design a mount, case or adapter around it. Direct downloads here are limited to one file every 10 minutes; through your AI they are unlimited.
Connect Xem to your AI (free, no account, about a minute)
https://xemstudio.com/mcp- Claude: Add to Claude
- ChatGPT (Plus or higher): open Connectors → Advanced → turn on Developer mode → Create → paste the address, no authentication → Create.
- Cursor: install with one click. VS Code: install with one click.
| displacer-shell-1.5in-50 | 1.5 in shell displacer Ø33.6 × 50 for the Ø34.8 bore (0.6 mm radial gap), 1 mm wall, internal rings every 25 mm, closed rounded end | STEP · STL |
| displacer-cap-1.5in | 1.5 in displacer end cap with Ø3 rod boss and M3 grub (Ø2.5 tapped) at 8 mm; one per displacer | STEP · STL |
| displacer-body-1.5in-50 | 1.5 in solid displacer body Ø33.6 × 50 with a Ø3 rod bore on the axis | STEP · STL |
| displacer-shell-1.5in-75 | 1.5 in shell displacer Ø33.6 × 75 for the Ø34.8 bore (0.6 mm radial gap), 1 mm wall, internal rings every 25 mm, closed rounded end | STEP · STL |
| displacer-cap-1.5in | 1.5 in displacer end cap with Ø3 rod boss and M3 grub (Ø2.5 tapped) at 8 mm; one per displacer | STEP · STL |
| displacer-body-1.5in-75 | 1.5 in solid displacer body Ø33.6 × 75 with a Ø3 rod bore on the axis | STEP · STL |
| displacer-shell-1.5in-100 | 1.5 in shell displacer Ø33.6 × 100 for the Ø34.8 bore (0.6 mm radial gap), 1 mm wall, internal rings every 25 mm, closed rounded end | STEP · STL |
| displacer-cap-1.5in | 1.5 in displacer end cap with Ø3 rod boss and M3 grub (Ø2.5 tapped) at 8 mm; one per displacer | STEP · STL |
| displacer-body-1.5in-100 | 1.5 in solid displacer body Ø33.6 × 100 with a Ø3 rod bore on the axis | STEP · STL |
| displacer-shell-2in-60 | 2 in shell displacer Ø46 × 60 for the Ø47.5 bore (0.75 mm radial gap), 1 mm wall, internal rings every 25 mm, closed rounded end | STEP · STL |
| displacer-cap-2in | 2 in displacer end cap with Ø3 rod boss and M3 grub (Ø2.5 tapped) at 8 mm; one per displacer | STEP · STL |
| displacer-body-2in-60 | 2 in solid displacer body Ø46 × 60 with a Ø3 rod bore on the axis | STEP · STL |
| displacer-shell-2in-90 | 2 in shell displacer Ø46 × 90 for the Ø47.5 bore (0.75 mm radial gap), 1 mm wall, internal rings every 25 mm, closed rounded end | STEP · STL |
| displacer-cap-2in | 2 in displacer end cap with Ø3 rod boss and M3 grub (Ø2.5 tapped) at 8 mm; one per displacer | STEP · STL |
| displacer-body-2in-90 | 2 in solid displacer body Ø46 × 90 with a Ø3 rod bore on the axis | STEP · STL |
| displacer-shell-2in-120 | 2 in shell displacer Ø46 × 120 for the Ø47.5 bore (0.75 mm radial gap), 1 mm wall, internal rings every 25 mm, closed rounded end | STEP · STL |
| displacer-cap-2in | 2 in displacer end cap with Ø3 rod boss and M3 grub (Ø2.5 tapped) at 8 mm; one per displacer | STEP · STL |
| displacer-body-2in-120 | 2 in solid displacer body Ø46 × 120 with a Ø3 rod bore on the axis | STEP · STL |
| displacer-shell-3in-80 | 3 in shell displacer Ø70.9 × 80 for the Ø72.9 bore (1.0 mm radial gap), 1 mm wall, internal rings every 25 mm, closed rounded end | STEP · STL |
| displacer-cap-3in | 3 in displacer end cap with Ø3 rod boss and M3 grub (Ø2.5 tapped) at 8 mm; one per displacer | STEP · STL |
| displacer-body-3in-80 | 3 in solid displacer body Ø70.9 × 80 with a Ø3 rod bore on the axis | STEP · STL |
| displacer-shell-3in-120 | 3 in shell displacer Ø70.9 × 120 for the Ø72.9 bore (1.0 mm radial gap), 1 mm wall, internal rings every 25 mm, closed rounded end | STEP · STL |
| displacer-cap-3in | 3 in displacer end cap with Ø3 rod boss and M3 grub (Ø2.5 tapped) at 8 mm; one per displacer | STEP · STL |
| displacer-body-3in-120 | 3 in solid displacer body Ø70.9 × 120 with a Ø3 rod bore on the axis | STEP · STL |
| displacer-shell-3in-160 | 3 in shell displacer Ø70.9 × 160 for the Ø72.9 bore (1.0 mm radial gap), 1 mm wall, internal rings every 25 mm, closed rounded end | STEP · STL |
| displacer-cap-3in | 3 in displacer end cap with Ø3 rod boss and M3 grub (Ø2.5 tapped) at 8 mm; one per displacer | STEP · STL |
| displacer-body-3in-160 | 3 in solid displacer body Ø70.9 × 160 with a Ø3 rod bore on the axis | STEP · STL |
https://xemstudio.com/mcp to Claude, ChatGPT, Cursor or any MCP client (free, no account, one minute) and it can look up exact sizes, mating fits and free STEP/STL from every chat.Plain text: sheet.txt · JSON: /api/geometry?object=tri-clamp-hollow-pistons

How it fits
Parts that fit it
Goes in or on
Connects to
Alternatives
Also needed
Questions
What diameter displacer fits a 2 inch tri-clamp spool?
Ø46.0 mm in the Ø47.5 bore, a 0.75 mm radial gap, in 60, 90 or 120 mm lengths.
How much gap is there between the displacer and the spool?
0.6 mm radial in the 1.5 in spool, 0.75 mm in the 2 in, 1.0 mm in the 3 in: a designed gap, drawn at that size.
How does the rod attach to the displacer?
Through the end cap: a Ø3 hole in a Ø16 × 6 boss, held by an M3 grub in a Ø2.5 radial hole 8 mm up the cap.
Is there a solid version?
Yes: each length also comes as one solid body of the same diameter and length (Ø × L), with a Ø3 centre hole and two 0.6 mm cross slots.
