Honeycomb and spiral stacks for tri-clamp spools: Ø34.8, Ø47.5 and Ø72.9
What honeycomb or spiral stack fits a tri-clamp spool? · Hardware · basis: Stack OD = 16 ga spool bore (34.8 / 47.5 / 72.9), exact; channel width 2–4 thermal penetration depths (δκ ≈ 0.26 mm in air at 1 bar, 100 Hz; 0.15 mm at 300 Hz), Swift
Also called: thermoacoustic engine stack, thermoacoustic stack stl, honeycomb stack, thermoacoustic resonator length, thermoacoustic refrigerator stack
Used in Long Earth Society builds. 3-foot Stirling engine
Exact dimensions. Every file is drawn at true size with no tolerance added. The holes and pins that meet another part are listed below under Mating features, with the fit each joint needs; open those by your process's clearance before making the part. Mating features
- sizes
- 3 in table
Notes
- The stack is the core of a standing-wave thermoacoustic engine: many narrow parallel channels between a hot face and a cold face, sitting in the resonator tube. It is drawn at the spool bore, so it is held in the bore itself.
- Honeycomb stack (1.5 and 2 in, × 40): hexagonal cells 1.5 mm across flats with 0.4 mm walls, every cell whole inside a 0.4 mm outer ring. Spiral stack (all three sizes, × 30, 40 and 50): one 0.4 mm wall wound with a 1.0 mm gas gap from a Ø6 core to a 0.5 mm outer ring.
- Channel size: half-width 2–4 × δκ, δκ = √(κ / (π f ρ cp)), so about 1–1.5 mm channels at 100 Hz and about 1.0 mm at 300 Hz in air at 1 bar.
- Placement: centred about λ/8 from the closed (hot) end of a λ/4 resonator; a closed-open tube resonates at f = c / 4L (150 Hz → 572 mm, 300 Hz → 286 mm in air at 20 °C).
Honeycomb and spiral stacks for tri-clamp spools: Ø34.8, Ø47.5 and… size chart
| spool (in) | stack od (mm) | forms | lengths (mm) | quarter wave 150hz (mm) | half wave 150hz (mm) |
|---|---|---|---|---|---|
| 1.5 | 34.8 | honeycomb 1.5 mm cells / spiral 1.0 mm gap | 40 / 30, 40, 50 | 572 | 1143 |
| 2 | 47.5 | honeycomb 1.5 mm cells / spiral 1.0 mm gap | 40 / 30, 40, 50 | 572 | 1143 |
| 3 | 72.9 | spiral 1.0 mm gap | 30, 40, 50 | 572 | 1143 |
Mating features
Drawn at the exact size. Open press, slide, run and socket features by your process's clearance (tolerances by process); leave designed gaps and clamp fits as drawn.
| feature | exact | mates with | fit | files |
|---|---|---|---|---|
| stack OD | spool bore (34.8 / 47.5 / 72.9) | tri-clamp spool bore | socket | stack-* |
Where the files are
Other publishers' files are linked, not hosted. "verify" = check the license at the link before commercial use.
| Wikipedia | Thermoacoustic heat engine | web | CC BY-SA 4.0 (text) |
| G. W. Swift (LANL) | Thermoacoustics: A Unifying Perspective for Some Engines and Refrigerators (textbook; DeltaEC software free) | web, software | LANL verify |
| NASA (NTRS, public domain) | Thermoacoustic Stirling heat engine for space power | US Government work, public domain | |
| Long Earth Society | Engine builds | web, video | LES site |
Free files
★ Free files 11 parts. Xem Studio design: free to use, print and sell things from; not to be republished as files. Xem Studio Design License. index.json
Use this part in your AI. Your AI gets the exact sizes and files straight from Xem and can design a mount, case or adapter around it. Direct downloads here are limited to one file every 10 minutes; through your AI they are unlimited.
Connect Xem to your AI (free, no account, about a minute)
https://xemstudio.com/mcp- Claude: Add to Claude
- ChatGPT (Plus or higher): open Connectors → Advanced → turn on Developer mode → Create → paste the address, no authentication → Create.
- Cursor: install with one click. VS Code: install with one click.
| stack-honeycomb-1.5in-40-c1.5 | honeycomb stack Ø34.8 × 40 (the 1.5 in spool bore, exact): 1.5 mm hexagonal cells, 0.4 mm walls | STEP · STL |
| stack-spiral-1.5in-30-g1.0 | spiral stack Ø34.8 × 30 (the 1.5 in spool bore, exact): one 0.4 mm wall wound with a 1.0 mm gas gap | STEP · STL |
| stack-spiral-1.5in-40-g1.0 | spiral stack Ø34.8 × 40 (the 1.5 in spool bore, exact): one 0.4 mm wall wound with a 1.0 mm gas gap | STEP · STL |
| stack-spiral-1.5in-50-g1.0 | spiral stack Ø34.8 × 50 (the 1.5 in spool bore, exact): one 0.4 mm wall wound with a 1.0 mm gas gap | STEP · STL |
| stack-honeycomb-2in-40-c1.5 | honeycomb stack Ø47.5 × 40 (the 2 in spool bore, exact): 1.5 mm hexagonal cells, 0.4 mm walls | STEP · STL |
| stack-spiral-2in-30-g1.0 | spiral stack Ø47.5 × 30 (the 2 in spool bore, exact): one 0.4 mm wall wound with a 1.0 mm gas gap | STEP · STL |
| stack-spiral-2in-40-g1.0 | spiral stack Ø47.5 × 40 (the 2 in spool bore, exact): one 0.4 mm wall wound with a 1.0 mm gas gap | STEP · STL |
| stack-spiral-2in-50-g1.0 | spiral stack Ø47.5 × 50 (the 2 in spool bore, exact): one 0.4 mm wall wound with a 1.0 mm gas gap | STEP · STL |
| stack-spiral-3in-30-g1.0 | spiral stack Ø72.9 × 30 (the 3 in spool bore, exact): one 0.4 mm wall wound with a 1.0 mm gas gap | STEP · STL |
| stack-spiral-3in-40-g1.0 | spiral stack Ø72.9 × 40 (the 3 in spool bore, exact): one 0.4 mm wall wound with a 1.0 mm gas gap | STEP · STL |
| stack-spiral-3in-50-g1.0 | spiral stack Ø72.9 × 50 (the 3 in spool bore, exact): one 0.4 mm wall wound with a 1.0 mm gas gap | STEP · STL |
https://xemstudio.com/mcp to Claude, ChatGPT, Cursor or any MCP client (free, no account, one minute) and it can look up exact sizes, mating fits and free STEP/STL from every chat.Plain text: sheet.txt · JSON: /api/geometry?object=tri-clamp-honeycomb-spiral-stacks

How it fits
Goes in or on
Connects to
Also needed
You might also need
Questions
What channel size should a thermoacoustic stack have?
2–4 thermal penetration depths: about 1–1.5 mm in air at 1 bar and 100–300 Hz.
How long should a thermoacoustic tube be?
Closed-open (λ/4): L = 343 / (4f): 286 mm for 300 Hz, 429 mm for 200 Hz, 858 mm for 100 Hz; closed-closed is twice that.
Where does the stack go?
Centred about λ/8 from the closed hot end: 107 mm in a 429 mm (200 Hz) λ/4 tube.
What diameter is the stack for a 2 inch spool?
Ø47.5, the 16 ga bore: a honeycomb stack × 40 or a spiral stack × 30, 40 or 50.
